Menu Elements

Navigation through the Menu window
The Menu will be shown on the right side of the Display by pressing the
MENU/ESC key. Use the rotor located on the right of the IPF-316 to scroll through
the different elements of the Menu,. Turning the rotor clockwise will scroll down the
Menu items, conversely turning the rotor counterclockwise will scroll up the Menu.
To enter a sub-menu, simply select it and then press the same rotor (ENTER).
To go back in the different sub-menus just press the MENU/ESC key.
Menu window elements
Each of the sub-menus will give access to the visualization and modification of the values of different
parameters of the device:
• 
AUDIO:






• INDICATORS: 

• 
VISIBILITY:


• 
LOCK:

•
PRIVATE CALL: It allows establishing a point-to-point connection with any of the devices that belong
to the system. This sub-menu will list the name of available devices on the system to
make a private call. You can not make a private call with an IPX-301 Interface user.
• REPLAY: It will play the last few seconds of listening received on the device. The REPLAY
time is defined through the NEBULA configuration software.
Replay function is default set in front panel F1 key.
ALTAIR IPcom Series: Model IPF-316
Mic Gain: Modifies the microphone gain. [1-10]
Sidetone Gain: Modifies sidetone gain. [1-5]
Line IN Gain: Modifies input gain via XLR. [1-10]
Line OUT Volume: Modifies output volume via XLR. [1-16]
Program Input Volume: Modifies the volume of the Program Input. [1-16]
Main Volume: Modifies the overall volume of the device. [1-16]
Speaker Volume: Modifies the volume of the internal speaker. [1-16]
Name: Shows the name of the device and allows to modify it.
Buzzer: Turns Buzzer on or off on the device. [ON-OFF]
Brightness: Modifies the brightness of the display. [1-16]
LED Brightness: Modifies the brightness of the key LEDs. [1-10]
All Lights off CFG: When this parameter is activated, the unit completely
disables the LED illumination of all the keys. [ON-OFF]
Lock CH [1-16]: Allows individually blocking the keys of each of the 16
channels. [ON-OFF]
Lock Keys: Lock all keys on the device. [ON-OFF]
