Audio Inputs / Audio Outputs

The unit can connect to a standard analogue audio signals by the Audio Input and Audio Output XLR3
connectors. The connection pinout is as follows:
Both IN and OUT ports are balanced. The input circuit is electronically balanced and the output is
electronically floating balanced output for better coupling and noise rejection.

Call Attention

To make a CALL attention to all members of a group, hold up the TALK/LISTEN key for >1 seconds on the
corresponding channel. On the display of all the devices that belong to the group, a message will be shown
indicating the user who is making the call and the group to which the call is being made.
To ensure silence in calls, the buzzer and vibrator must be disabled locally or through the NEBULA software.
On systems with many users, the CALL can be initiated automatically by following the action of pressing a
TALK key to automate recognition of the caller. This option is set from NEBULA in the USERS>ADVANCED
□
SETTINGS>GENERAL
Maybe in this scenario it is advisable to set the TALK LATCH disabled on some groups to guarantee a brief
message, leaving the system operative for additional short voice messages.
Operation: USERS>Channel Config> "choose a channel" >TALK LATCH Enabled/Disabled

Private Calls

It is possible to initiate a private conversations at any time to any of the users on the system.
To do so, find on the main MENU the PRIVATE CALL menu option and scroll across all users available.
Press ENTER to establish the private call.
Destination user must accept with ENTER or refuse the call by ESC
Finish the private call by pressing again ENTER
Private Call can be further automated by assigning a channel dedicated to a destination unit. To do so, go to
USERS > CHANNEL CONFIG and by selecting a channel configure it in TYPE as Pivate Call, then select the
destination of the communication in the USER from a table of available users.
NOTE: Interface stations IPX-301 are no considered here for private call destinations because it is a
no operator station.
ALTAIR IPcom Series: Model IPF-316
IN/OUT XLR 3 PINOUT
Pin 1 GND
Pin 2 +Positive
Pin 3 - Negative
"Send Call when Talk key is activated"
