WIRELESS DUAL CHANNEL MANAGER BELTPACK
WB-200 SERIES WIRELESS INTERCOM SYSTEM
CEINTURE PACK HF
BELPACK EINHEIT
WBP-202
OWNERS MANUAL
EQUIPOS EUROPEOS ELECTRÓNICOS, S.A.L
Avda. de la Industria, 50. 28760 TRES CANTOS-MADRID (SPAIN).
34-91-761 65 80
www.altairaudio.com
Issue May 09
AUDIO ELECTRONICS DESIGN
AUDIO ELECTRONICS DESIGN
AUDIO ELECTRONICS DESIGN
AUDIO ELECTRONICS DESIGN
34-91-804 43 58
altair@altairaudio.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WBP-202 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Altair WBP-202

Summary of Contents for Altair WBP-202

  • Page 1 WBP-202 WIRELESS DUAL CHANNEL MANAGER BELTPACK WB-200 SERIES WIRELESS INTERCOM SYSTEM OWNERS MANUAL Issue May 09 CEINTURE PACK HF BELPACK EINHEIT AUDIO ELECTRONICS DESIGN AUDIO ELECTRONICS DESIGN AUDIO ELECTRONICS DESIGN AUDIO ELECTRONICS DESIGN EQUIPOS EUROPEOS ELECTRÓNICOS, S.A.L Avda. de la Industria, 50. 28760 TRES CANTOS-MADRID (SPAIN).

  • Page 2: Table Of Contents

    WBP-202 WIRELESS DUAL CHANNEL MANAGER BELTPACK. 1. INTRODUCTION............................3 2. SWITCHES, CONTROLS, ADJUSTMENTS AND CONNECTORS ..............4 FRONT PANEL...................................4 REAR PANEL..................................4 3. OPERATION..............................4 HEADSET CONNECTION..............................5 CHANNEL SELECTION SWITCH ............................5 CHANNEL LISTENING BALANCE............................6 CALL SWITCH...................................6 MIC ON/OFF/PUSH TO TALK SWITCH (TALK)........................7 BUZZER ON/OFF SWITCH..............................7 VOLUME UP/DOWN SWITCH ............................7...

  • Page 3: Introduction

    It is very important to read it carefully, mainly the paragraphs marked as NOTE, PRECAUTION and DANGER, for your security. Save the original packing, you can re-use it to transport the unit. NEVER SHIP THE ALTAIR WBP-202 WITHOUT ITS ORIGINAL PACKING.

  • Page 4: Switches, Controls, Adjustments And Connectors

    WBP-202 WIRELESS DUAL CHANNEL MANAGER BELTPACK. 2. SWITCHES, CONTROLS, ADJUSTMENTS AND CONNECTORS Switches, controls, adjustments and connectors that you can find in your ALTAIR intercom beltpack. The description and explanation of each one will be found in the corresponding section.

  • Page 5: Headset Connection

    In order to begin to use its new beltpack ALTAIR WBP-202, first turn on the base station on which the beltpack is registered (if it is not registered to any base, goes to the registry section).

  • Page 6: Channel Listening Balance

    WBP-202 WIRELESS DUAL CHANNEL MANAGER BELTPACK. LISTENING The listening channel depends also of the selected channel indicated by the lamps. By selecting AB, you can listen both channels simultaneously. A balance listening between channels is allowed in each of the 3 possible selections A, AB and B. By using this balance, you can listening the opposite channel at a small, say 20 % level, helping management of both channel crews at a time.

  • Page 7: Mic On/Off/Push To Talk Switch (Talk)

    The unit provides a BUZZER-KILL (turns off the BUZZER) system, so that when the buzzer is enabled it is possible to muted it by the BUZZER-KILL function of the base station ALTAIR WBP-202 or a master station ALTAIR EF-200, connected to the base station. This is a proprietary BUZZER-KILL system, so it is not compatible with other intercom systems on the market The BUZZER could be disabled with an internal preset.

  • Page 8: Keyboard Beep Regulation

    WBP-202 WIRELESS DUAL CHANNEL MANAGER BELTPACK. BATTERY led indicates the first step, the BUZZ ON/OFF led indicates the fourth step, the MIC ON/OFF led indicates the seventh step and the IN RANGE led the tenth step of volume. This 2 arrow keys are used by another functions on the beltpack as depicted.

  • Page 9: Standby Mode

    WBP-202 WIRELESS DUAL CHANNEL MANAGER BELTPACK. STANDBY MODE When the beltpack is turn on and we press the ON/OFF switch and the VOLUME DOWN switch at the same time, the beltpack change to STANDBY mode. In this mode, the beltpack can...

  • Page 10: Beltpack Deregistration

    WBP-202 WIRELESS DUAL CHANNEL MANAGER BELTPACK. Each beltpack can be registered in two different base stations, so that if it loses the range of one, changes the operation to the other base station. Each base station can register a maximum of four beltpacks.

  • Page 11: Cancelling The Buzzer

    WBP-202 WIRELESS DUAL CHANNEL MANAGER BELTPACK. When using electret type mics, MIC level must be set to around 5 steps higher than minimum position as general recommendation. Set also the SIDE TONE setting accordingly. CANCELLING THE BUZZER The buzzer can be disabled definitely by removing a jumper JP1/BUZZER located near the buzzer on the upper-right side of the unit.

  • Page 12: Troubleshooting Guide

    WBP-202 WIRELESS DUAL CHANNEL MANAGER BELTPACK. 6. TROUBLESHOOTING GUIDE WHEN: POSSIBLE CAUSES AND SOLUTIONS 1) Abnormal low range. a) With the beltpacks on, switch off the base station, wait for 30 seconds and then switch on to reorganize links. 2) Beltpack switch-on but does not link a) Beltpack is not registered.

  • Page 13: Battery Charger Altair Wbpc-200

    CHANGING THE VOLTAGE AND THE FUSE The battery charger ALTAIR WBPC-200 is set to operate at 230V, 50-60Hz and at 115V, 50-60Hz. Make sure that the unit is disconnected of the mains. In the unit rear panel, is placed the mains connector, the mains selector and the fuse holder.

  • Page 14: Connecting To The Mains

    For a full charge, it is recommended a 2 hours minimum charging in this state. If a problem appears in one of the connectors, and the consumption increases, the battery charger ALTAIR WBPC-200 will protect itself, and the LED associated to this connector will turn to red colour.

  • Page 15: Technical Specifications

    WBP-202 WIRELESS DUAL CHANNEL MANAGER BELTPACK. 8. TECHNICAL SPECIFICATIONS PREAMPLIFIER • MICROPHONE TYPE: Dynamic or electret. • INPUT IMPEDANCE: 4K7. • NOMINAL LEVEL: -45 dBu. • PHANTOM VOLTAGE: +9 VDC (internal preset ). HEADSET AMPLIFIER • 200 Ω (nominal), 2KΩ (maximum).

  • Page 16: Warranty

    WBP-202 WIRELESS DUAL CHANNEL MANAGER BELTPACK. 9. WARRANTY This unit is warranted by Equipos Europeos Electrónicos to the original user, against flaws in the manufacturing and in the materials, for a period of two years (one year depending on some countries), starting from the date of sale.
  • Page 17 WBP-202 WIRELESS DUAL CHANNEL MANAGER BELTPACK. Extract of the Declaration of Conformity (DoC) “We, Equipos Europeos Electrónicos, S.A.L., declare, that the above mentioned product is manufactured according to our Full Quality Assurance System in compliance with ANNEX V of the R&TTE-Directive 99/5/EC. The presumption of comformity with the essential requirements regarding Council Directive 99/5/EC is ensured.”...
