Altair IPcom Series User Manual page 23

TECHNICAL SPECIFICATIONS
FREQUENCY RESPONSE
DYNAMIC RANGE
SYSTEM
SPECIFICATIONS LATENCY
POWER REQUIREMENTS (alternate)
MICROPHONE TYPE (Headset)
MICROPHONE TYPE (Panel Mic)
PREAMPLIFIER
MICROPHONE INPUT IMPEDANCE
NOMINAL / MAXIMUM LEVEL
PHANTOM VOLTAGE
IMPEDANCE
MAXIMUM LEVEL / OUTPUT LEVEL
HEADPHONE
AMPLIFIER
FREQUENCY RESPONSE
RESIDUAL NOISE
RATED POWER
SPEAKER AMPLIFIER
MAX SPL LEVEL
EXTERNAL CONNECTION
GPO x 5
GPIO PORTS
GPI x 5
+ POWER OUT
100/1000-Mbit/s Ethernet
ETHERNET PORT
PoE compatible
RECOMMENDED CABLE TYPE
ETHERNET CABLE
Maximum recommended cable length
ACCESSORIES
Headsets
(optional)
AC/DC adapter
ACCESSORIES
Gooseneck microphone
(included on the supply)
DIMENSIONS
Longitudinal measures
WEIGHT
Net without accessories
Temperature (operating)
ENVIRONMENTAL
CONDITIONS
Humidity (operating)
ALTAIR IPcom Series: Model IPF-316
TECHNICAL SPECIFICATIONS - Measured values
Note: Technical specifications subject to change without notice.
100 Hz – 24KHz (-3 dB) H / 12 Khz (-3 dB) L
80 dB
Typically < = 20 ms L
● +24V / 160 mA nominal. AC/DC adapter
● PoE 3 class / <5W
Dynamic (D) o Electret (E). Automatic Selection
Dynamic (D)
4K7
-40 dBu (D) / -20 dBu(E)
+9 VDC (Automatic Selection)
200 ohm (nominal); 2K ohm (maximum).
20 Vpp (200 ohm) / 250 mW (200 ohm).
250 Hz – 15 KHz.
-75 dBu (all mics off)
4 W @ 8 ohm
89 dB SPL @0,5m
Mini-jack 3.5 mm. Connection cancels internal speaker
3 pin 3.5 mm Euroblock / 40 V max DC, 200 mA max
3 pin 3.5 mm Euroblock / 40 V max DC, 100K pull-up
3V DC/ 100 mA max
IEEE802.3-2002 standard
IEEE802.af standard
CAT. 5E or higher (1000BASE-T)
100m
ALTAIR AM100 Series
ACPA-IP REF: VET-24
MF-200 Series 14" XLR4
1U rack (485×45 mm, 90mm) (LxWxD)
1700 gr
0ºC a 50ºC
10% a 90% (HR, not condensed)
23
