  • Page 1 WBP-200 SINGLE CHANNEL WIRELESS BELTPACK WB-200 SERIES WIRELESS INTERCOM SYSTEM OWNERS MANUAL AUDIO ELECTRONICS DESIGN AUDIO ELECTRONICS DESIGN AUDIO ELECTRONICS DESIGN AUDIO ELECTRONICS DESIGN EQUIPOS EUROPEOS ELECTRÓNICOS, S.A.L Avda. de la Industria, 50. 28760 TRES CANTOS-MADRID (SPAIN). 34-91-761 65 80 34-91-804 43 58 altair@altairaudio.com...

  • Page 2: Table Of Contents

    ACTIVATING THE MICROPHONE PHANTOM POWER ..............9 CANCELLING THE BUZZER......................9 CHANGING THE BATTERIES ......................9 5. SPECIAL RECOMMENDATIONS ..................... 10 6. BATTERY CHARGER ALTAIR WBPC-200 ..................10 CHANGING THE VOLTAGE AND THE FUSE ................... 10 CONNECTING TO THE MAINS......................11 BELTPACK BATTERY CHARGE ......................11 7.

  • Page 3: Introduction

    It is very important to read it carefully, mainly the paragraphs marked as NOTE, PRECAUTION and DANGER, for your security. Save the original packing, you can re-use it to transport the unit. NEVER SHIP THE ALTAIR WBP-200 WITHOUT ITS ORIGINAL PACKING.

  • Page 4: Switches, Controls, Adjustments And Connectors

    In order to begin to use its new beltpack ALTAIR WBP-200, first it turn on the base station on which the beltpack is registered (if it is not registered to any base, goes to the registry section).

  • Page 5: Headset Connection

    ALTAIR WBP-200. If the beltpack ALTAIR WBP-200 remains turned on during a period of ten minutes without connection to the base station (the base station is turned off, outside range, or the beltpack is not registered to any base station), it will be turned off automatically.

  • Page 6: Mic On/Off/Push To Talk Switch (Talk)

    The unit provides a BUZZER-KILL (turns off the BUZZER) system, so that when the buzzer is enabled it is possible to muted it by the BUZZER-KILL function of the base station ALTAIR WBP-200 or a master station ALTAIR EF-200, connected to the base station. This BUZZER-KILL system is compatible with other intercom systems of the market.

  • Page 7: In Range Led

    WBP-200 SINGLE CHANNEL WIRELESS BELTPACK. To turn off the beltpack, press and hold two seconds the ON/OFF switch when the beltpack is turned on. In this moment will sound the buzzer (if the buzzer is turn on) and when the ON/OFF switch it is depressed, the beltpack it is turned off.

  • Page 8: Beltpack Registration

    WBP-200 SINGLE CHANNEL WIRELESS BELTPACK. BELTPACK REGISTRATION Each beltpack can be registered in two different base stations, so that if it loses the range of one, changes the operation to the other base station. Each base station can register a maximum of four beltpacks.

  • Page 9: Activating The Microphone Phantom Power

    WBP-200 SINGLE CHANNEL WIRELESS BELTPACK. NOTE: This type of operations takes place with the unit is opened; the best thing should be to carry it out by a qualified technician. Care must be taken to avoid short circuit between battery holders, etc.

  • Page 10: Special Recommendations

    CHANGING THE VOLTAGE AND THE FUSE The battery charger ALTAIR WBPC-200 is set to operate at 230V, 50-60Hz and at 115V, 50-60Hz. Make sure that the unit is disconnected of the mains. In the unit rear panel, is placed the mains connector, the mains selector and the fuse holder.

  • Page 11: Connecting To The Mains

    For a full charge, it is recommended a 2 hours minimum charging in this state. If a problem appears in one of the connectors, and the consumption increases, the battery charger ALTAIR WBPC-200 will protect itself, and the LED associated to this connector will turn to red colour.

  • Page 12: Technical Specifications

    WBP-200 SINGLE CHANNEL WIRELESS BELTPACK. 7. TECHNICAL SPECIFICATIONS PREAMPLIFIER • MICROPHONE TYPE: Dynamic or electret. • INPUT IMPEDANCE: 4K7. • NOMINAL LEVEL: -45 dBu. • PHANTOM VOLTAGE: +9 VDC (internal preset ). HEADSET AMPLIFIER • 200 Ω (nominal), 2KΩ (maximum).

  • Page 13: Warranty

    WBP-200 SINGLE CHANNEL WIRELESS BELTPACK. 8. WARRANTY This unit is warranted by Equipos Europeos Electrónicos to the original user, against flaws in the manufacturing and in the materials, for a period of one year, starting from the date of sale.
