Summary of Contents for Altair IPcom IPA-304
- Page 1 IPcom Series Digital Intercom Audio Interface Over IP ALTAIR IPcom IPA-304 Quad channel AES67><Altair IPcom Interface USER MANUAL Feb 24 version AUDIO | BROADCAST | COMMUNICATION PRODUCTS www.altairaudio.com COPYRIGHT Equipos Europeos Electrónicos...
-
Page 2: Table Of Contents
Appendix OR-1-301 RACK ACCESSORY FOR ALTAIR IPX-301/IPX-302/IPA-304........18 WARRANTY........................19 Contact and Links.......................21 Included in the supply 1x IPA-304. Four channel AES67>< 4x6 channels Altair IPcom Interface 2x 3 pin 3.50 Euroblock connectors 1x Set of adhesive feet 1x Operating Manual... -
Page 3: Introduction
Te unit converts audio digital streams present on the LAN and for this reason has not analog or digital external ports. Like the rest of the Altair IPcom Series device, the NEBULA Configuration Software will be used to assign intercom groups, define the different audio levels and configure all the parameters of the unit. - Page 4 AES67 streams AES67 Inputs: AES67 streams present on the Network and generated by external AoIP devices. AES67 Outputs. AES67 streams generated by the Altair Interface to reach external AoIP devices. IPcom streams IPcom Inputs: Intercom signals present on the Network generated by the IPcom system.
-
Page 5: Hardware
ALTAIR IPcom Series: IPA-304 HARDWARE Front and Rear Panels FRONT PANEL REAR PANEL Controls Front Panel GPO Ports O1 / O2 Fitted with standard (3.5 pitch) Phoenix™ Euroblock connector for General Purpose Output signals. The IPA-304 includes two general purpose logic outputs. These GPO are open collector type and simulates the behavior of a NO (normally open) switch that closes when activated. - Page 6 ALTAIR IPcom Series: IPA-304 GPI Ports I1 / I2 Fitted with standard (3.5 pitch) Phoenix™ connector for General Purpose Input signals. The IPA-304 includes two general purpose logic inputs I1 and I2. Both GPIs are a digital inputs, with an internal 100 Kohm pull-up tied internally to 3V rail, and therefore the simplest assembly is a simple switch to ground.
-
Page 7: Operation
ALTAIR IPcom Series: IPA-304 OPERATION Interface turn-on The IPA-304 interface stations as well as the rest of the devices of the Ipcom series do not have a power button and their operation is subject to the switch-on of the switch to which they belong. -
Page 8: Aes67 Tx. Creating An Aes67 Stream
ALTAIR IPcom Series: IPA-304 AES67 Tx. Creating an AES67 Stream. The IPcom interface will generate an AES67 flow from an IPcom signal(Group) AES 67 Tx On the NEBULA software, select the device IPA304 from the Users list On the channel list, go to a channel (CH1 to 24) and select from the desired Group you want to stream on the network. -
Page 9: Leveling Aes67 Tx Streams
ALTAIR IPcom Series: IPA-304 Operation of the Controllers must be done in the Native AES67 space. No other VoIP protocols than AES67 are created nor received by the IPA Interface. Leveling AES67 Tx Streams The different IPcom channels can be individually leveled (MIX) or muted (Listen) and the result mix are leveled and sent to the four selected AES67 OUTPUTS by accessing to the NEBULA “Advanced Settings”... -
Page 10: Leveling Aes67 Rx Streams
ALTAIR IPcom Series: IPA-304 The AES67 streams present on the network are “discovered” by the IPcom system as shown on the above NEBULA tab. Those streams are present on the AoIP Controllers as “Receivers” and can be routed to the present “Transmitters”... -
Page 11: Talk
ALTAIR IPcom Series: IPA-304 Talk The Talk concept in this device refers to the signal entering the interface. This signal can be either a balanced or unbalanced analogue signal (IN XLR). This signal is named 4W four wires to differentiate from the standard 2W used for wired intercom. -
Page 12: Call Signaling From Unit
ALTAIR IPcom Series: IPA-304 Call signaling from unit To make a CALL attention to all members of a group, press F1 / F2 function key on the interface unit buttons. This key must be set previously programmed as a Call to Group function. To do so, enter to the NEBULA window F. -
Page 13: Use Cases
IPcom System ↔ Intercom Matrix Panels w/ AES67 ports The example shows how the IPcom system interfaces with an intercom matrix system by using the IPA-304 unit as a communication bridge between both worlds: the Altair IPcom System and any AES67 compliant device streaming AoIP. -
Page 14: Ipcom System ↔ Sending/Receiving Audio Aes67 Streaming
The example shows how the IPcom system helps interfacing a 2W intercom systems to an AoIP system compliant with the AES67 standard. 2W (2 wire) intercom systems as the Altair Wireless system or Altair party-line can be connected to digital audio networks. -
Page 15: Nebula Configuration Software
ALTAIR IPcom Series: IPA-304 NEBULA CONFIGURATION SOFTWARE Configuration windows The configuration software for the entire ALTAIR IPcom Series contains 6 main windows: Groups It shows all the groups created in the system, indicates the different devices that belong to each group and allows assigning a group configuration for each particular device. -
Page 16: Advanced Settings
ALTAIR IPcom Series: IPA-304 NEBULA CONFIGURATION SOFTWARE Advanced Settings IPA-304 Interface Advanced Settings Window The window gives access to the complete configuration of the IPA-304 Interface including File and Edit operations. The window contains 4 tabs that show the different configuration parameters available. - Page 17 ALTAIR IPcom Series: IPA-304 Audio IPA-304 audio configuration parameters: AES67 Input and output gains and Mix level of the different channels, Talk and listening activation keys per channel. AES67 Show the configuration of the AES67 streams. AES INPUT CONFIGURATION. Shows the different Announced Streams on the Network allowing selection of the available channels.
- Page 18 ALTAIR IPcom Series: IPA-304 Ethernet Allows you to activate/deactivate DHCP and, where appropriate, allows you to assign a static IP to selected IPA-304. Note: For further information on the operation of the Configuration Software, review the specific manual.
-
Page 19: Technical Specifications
ALTAIR IPcom Series: IPA-304 TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS FREQUENCY RESPONSE 100 Hz – 10 KHz (-3 dB) DYNAMIC RANGE 80 dB IPcom SYSTEM SPECIFICATION ● +24V / 120 mA nominal. AC/DC adapter POWER REQUIREMENTS (alternate) ● PoE 3 Class 1 to 4 Multicast Native AES67 OUTPUT AES67 STREAMS Encapsulation Up to 4 audio channels. -
Page 20: Appendix Or-1-301 Rack Accessory For Altair Ipx-301/Ipx-302/Ipa-304
Appendix OR-1-301 RACK ACCESSORY FOR ALTAIR IPX-301/IPX-302/IPA-304 ASSEMBLY INSTRUCTIONS: 20 mm 130 mm 240 mm 1. Attach IPx-30x using 4 M3x5 screws, 2 at the front and 2 at the rear of both IPX-30x (Figure 1). 2. Remove the original side screws of the IPX-30x´Ss located at the ends (Figure 2). -
Page 21: Warranty
Altair expressly disclaims any responsibility for such usage which shall be made at your sole risk, even if Altair has been informed in writing of such usage. Unless expressly designated in writing by Altair as suitable for use in aerospace applications, you shall not use the above products in... - Page 22 European Union Waste Electronics Information Unión Europea Información sobre residuos electrónicos Waste from Electrical and Electronic Equipment (WEEE) directive The WEEE logo signifies specific recycling programs and procedures for electronic products in countries of the European Union. We encourage the recycling of our products. If you have further questions about recycling, contact your local sales office.
-
Page 23: Contact And Links
Contact and Links _______________________________________ Web Page www.altairaudio.com _______________________________________ Social Media : /AltairAudio : /AltairAudio : /AltairAudio : /AltairAudio : @AltairAudio : @AltairAudio _______________________________________ Product catalog www.altairaudio.com/products _______________________________________ Technical Support Contact: +34 918043265 _______________________________________ AUDIO | BROADCAST | COMMUNICATION PRODUCTS www.altairaudio.com COPYRIGHT Equipos Europeos Electrónicos...
