Service Manual
Specifications
Dimensions-Operating
Standard Forks Forks Down
Adjustable Forks Forks Down
Boom
Note: measured from ground to bottom of shackle
Load Platform Forks Down
Note: Can be used with standard forks and adjustable forks only
Pipe Cradle Option: handles round objects up to 30 in / 76 cm in diameter
Note: Can be used with standard forks and adjustable forks only (see above for working heights)
Non-marking Fork Option
Note: Can be used with standard forks and adjustable forks only (see above for working heights)
Fork Extension Option
Note: can be used with standard forks and adjustable forks only (see above for working heights)
10
SLC-6
5 ft 8 in
1.7 m
Forks Up 7 ft 5 in
2.3 m
5 ft 8 in
1.7 m
Forks Up 6 ft 7 in
2.3 m
6 ft 8 in
2 m
5ft 8 in
1.7 m
Forks Up 7 ft 5 in
2.3 m
Superlift Contractor
SLC-12 SLC-18
11 ft 2in 16 ft 9 in
3.4 m 5.1 m
12 ft 11 in 18 ft 6 in
3.9 m 5.6 m
9 ft 9 in 14 ft 7.5 in
3 m 4.5 m
11 ft 5.5 m 16 ft 4 in
3.9 m 5.6 m
12 ft 2 in 17 ft 9 in
3.7 m 5.4 m
11 ft 2 in 16 ft 6 in
3.4 m 5.1 m
12 ft 11 in 18 ft 6 in
3.9 m 5.6 m
June 2018
SLC-24
22 ft 3 in
6.8 m
24 ft
7.3 m
19 ft 6 in
5.9 m
21 ft 2.5 in
7.3 m
23 ft 3 in
7.1 m
22 ft 3 in
6.8 m
24 ft
7.3 m
Part No. 115409
