- Page 1 Operator's Manual Supplement Panel Cradle and Z Booms ® ® ANSI/CSA North America South America Asia Original Instructions Second Edition Fourth Printing Part No. 1299254GT...
- Page 2 Copyright © 2020 by Terex Corporation Second Edition: Fourth Printing, November 2023 Genie, "S" and "Z" are registered trademarks of Terex South Dakota, Inc. in the U.S.A. and many other countries. "XC" is a trademark of Terex South Dakota, Inc.
- Page 3 Second Edition • Fourth Printing Operator's Manual Supplement Introduction Modification Approval: These instructions constitute authorization to modify a Genie machine listed below by attaching hardware to the platform rails for the purpose of lifting solid panels, provided the criteria herein is strictly adhered to.
-
Page 4: Installation Instructions
Operator's Manual Supplement Second Edition • Fourth Printing Installation Instructions Installation Instructions Observe and Obey: This procedure shall be completed by a person authorized to install the Panel Cradle. Immediately tag and remove from service a damaged or malfunctioning machine. ... -
Page 5: Tools Required
Second Edition • Fourth Printing Operator's Manual Supplement Installation Instructions Panel Cradle Safety Tools Required Ratchet Bodily injury hazard. Failure to use the Genie Panel Cradle Ratchet extension according to the instructions and 3/8 inch socket safety rules listed here and in the Operator's and 1/2 inch socket Responsibilities Manual could... - Page 6 Operator's Manual Supplement Second Edition • Fourth Printing Installation Instructions Contents of Kit 1299220GT Contents of Kit 1298841GT Description Genie part Qty. Description Genie part Qty. number number Clamp, 1.25 x 0.5 inches, rubber- 56424GT Clamp, 1.25 x 0.5 inches, rubber- 56424GT cushion cushion...
- Page 7 Second Edition • Fourth Printing Operator's Manual Supplement Installation Instructions Panel Cradle Installation: Use the provided fasteners to secure the tray to the platform. Tighten the fasteners. Note: Perform this procedure on a firm, level surface with the boom in the stowed position. Genie part numbers 824086GT, 1274167GT Adjust the platform so that the toe board at the NOTE: Kit decals should already be installed onto...
- Page 8 Operator's Manual Supplement Second Edition • Fourth Printing Decal Inspection Decal Inspection Decal Inspection Use the inspection to verify that all decals are legible and in place. Part No. Decal Description 1298467GT Decal, Symbol, Read the Manual* 1298849GT Decal, Panel Cradle, Word* *These decals are model, option or configuration specific.
- Page 9 Second Edition • Fourth Printing Operator's Manual Supplement Operating Instructions Operating Instructions Operating Instructions: Secure the panel cradle and strap assembly to the platform. Center the load on the platform. Secure the load to the platform using the strap. Tighten the strap. Panel Cradle S®...
