Section 2 Specific ati ons
Model
Height-stowed
Width
Standard Base
Width-stabilizers lowered
(if equipped)
Length - Stowed
Length - Operating
Ground
Clearance
Load Capacity
at 14in / 36cm load center
Note: see Load Capacity Charts section for load capacities at other load centers.
Net Weight
Airborne Noise Emissions by Machinery
Maximum sound level at normal operating work stations (A-weighted)
Load Handling Attachments
Standard Forks
Adjustable Forks
Boom
Pipe Cradle
Load Platform
Fork extensions (each)
Part No. 115409
SLC-6 SLC-12
86 in 86 in
2.2 m 2.2 m
31.5 in 31.5 in
80 cm 80 cm
66 in 66 in
1.7 m 1.7 m
34 in 34 in
86.4 cm 86.4 cm
59 in 63 in
1.5 m 1.6 m
2 in 2 in
5.8 cm 5.8 cm
650 lbs 650 lbs
295 kg 295 kg
650 lbs 650 lbs
165 lbs 225 lbs
75 kg 102 kg
85 dB 85 dB
Length Width
28 in 23 in
71.1 cm 58.4 cm
27.5 in 11.5 in to 30 in
69.9 cm 29.2 cm to 76.2 cm
44 in 1.5 in
111.8 cm 3.8 cm
27.5 in 24.5 in
70 cm 63 cm
26.3 in 23 in
69.9 cm 58.4 cm
30 in 2 in
76 cm 5 cm
Superlift Contractor
Service Manual

Specifications

SLC-18 SLC-24
86 in 86 in
2.2 m 2.2 m
31.5 in 31.5 in
80 cm 80 cm
66 in 66 in
1.7 m 1.7 m
34 in 34 in
86.4 cm 86.4 cm
73 in 81 in
1.9 m 2 m
2 in 2 in
5.8 cm 5.8 cm
650 lbs 650 lbs
295 kg 295 kg
650 lbs 650 lbs
307 lbs 347 lbs
139 kg 157 kg
85 dB 85 dB
Depth Net Weight
2.5 in 26.5 lbs
6.4 cm 12 kg
2.5 in 52.5 lbs
6.4 cm 23.8 kg
6 in 40 lbs
15.2 cm 18 kg
6 in 10 lbs
15.2 cm 4.5 kg
2.5 24 lbs
6.4 cm 11 kg
3 in 4.5 lbs
7.6 cm 2 kg
9
