Evaluation Module Overview
1 Evaluation Module Overview
1.1 Introduction
The ADC3669EVM allows for evaluation of all the devices in the ADC3x69 family, as the devices are all
pin-to-pin compatible. The ADC3669EVM is populated with an ADC3669, which can be configured to sample at
lower speeds to simulated the lower sample rate parts.
For data capture, the ADC3669EVM is connected to a TSW1418EVM via an FMC connector. The
TSW1418EVM is an FPGA data capture card which features the AMD Artix-7 FPGA. The ADC data, captured by
the FPGA, is then transferred to the PC and displayed in the HSDC Pro capture software.
This user's guide describes the characteristics, operation, and use of the ADC3669 evaluation module (EVM).

1.2 Kit Contents

Item
ADC3669EVM
USB 2.0 Mini-B Cable

1.3 Specification

The specifications for the ADC3669 can be found in the device's data sheet (SBASAL3).

1.4 Device Information

The ADC3669 can also be configured to disable the channel B input to simulate the single channel device. The
EVM is configured to receive external single-ended analog inputs as the EVM includes baluns for single-ended
to differential conversion. The sample clock is also sourced externally and is single-ended. For more details, the
device information for the ADC3669 can be found in the data sheet (SBASAL3).
2 ADC3669 Evaluation Module
Table 1-1. ADC3669EVM Kit Contents
Description
PCB
Cable
Copyright © 2024 Texas Instruments Incorporated
www.ti.com
Quantity
1
1
