Parts Breakdown
Model IC-CN-0089ST
Item No. Description
PC Board + Control Panel for
AL111
48054
AN280 Filter Net Assembly for 48054
AN281 Display Board PD-321B for 48054
Front Trim Panel Assembly for
AN282
48054
Filter Mesh Platemetal Frame for
AN283
48054
Door Panel Assembly - Black Gray
AN284
Color for 48054
Door Frame Assembly - Black
AN285
Gray Color for 48054
AN286 Condenser for 48054
AN287 Fan Blades for 48054
AN288 Fan Motor for 48054
AN289 PC Board for 48054
48054
Position Item No. Description
1 AN290 Left Column for 48054
Front Vent Window Assembly for
2 AN291
48054
3 AL113 Water Pump Assembly for 48054
4 AN293 Compressor NUT55NR for 48054
5 AN294 Exhaust Pipe Assembly for 48054
6 AN295 Defrost Valve Coil for 48054
7 AN296 Water Inlet Valve for 48054
8 AN297 Feet Assembly for 48054
9 AN298 Base Plate for 48054
10 AN299 Ice Full Sensor for 48054
11 AN300 Condensation Sensor for 48054
Position Item No.
12 AN301
13 AN302
14 AN303
15 AN304
16 AN305
17 AN306
18 AN307
19 AN308
20 AN309
21 AQ710
22 AQ711
30
Description Position
Drying Filter for 48054 23
Foam Box Assembly-Blue Color
(no Display Panel Hole on the 24
Side) for 48054
Return Air Pipe Assembly for
25
48054
Spray Pipe Assembly for 48054 26
Evaporator for 48054 27
Ice Skating Board for 48054 28
Cold LED Light 66481554 for
29
48054
Water Sink for 48054 30
Right Column for 48054 31
Bottled Water Base with Dust Cap
32, 33
for 48054
Bottled Water Base Fixing for
34
48054
