Operation - EIP KOMPACT 10240KP-GB Owner's Manual

The following procedures should be followed to test the Kompact for correct

operation:

1. After unpacking, examine all external features to confirm damage-
free shipment. Report all defects and damage at once. Connect the
power cable to a grounded 13 Amp electrical outlet. Connect a
suitably sized hose to the condensate outlet and run the hose to a
permanent drain.
2. Check dehumidification process as follows:
DO NOT REMOVE COVERS WHEN UNIT IS IN OPERATION
A. Place unit on a level surface.
B. Start up unit by switching to "ON".
C. Check that the compressor is running.
D. Leave the machine running for 15 minutes.
E. Observe the evaporator coils through the rear upper grille, to
confirm frost formation.
i.
frost should cover the entire evaporator coil.
ii.
of condensed water should cover the entire evaporator coil.
F. After continuous running time of approximately 55 minutes,
unit will enter "Hot Gas" defrost mode for several minutes and
then automatically return to normal operation.
If, after carrying out the above procedures, the unit does not appear to
function properly, refer to the Trouble Shooting section, which follows,
or contact the Factory Service Center.
ONCE THE UNIT HAS BEEN SWITCHED OFF, WAIT AT
LEAST FIVE MINUTES BEFORE RESTARTING.
After using the Kompact, turn it off for five minutes to allow the condensate on
the coils to drain into the pump reservoir, then turn it back on and press the
momentary purge switch for twenty to thirty seconds to evacuate the water
from the pump reservoir.
OPERATION
CAUTION:
If the air temperature is below 78°F, an even coating of
If the air temperature is above 78°F, frost and/or droplets
CAUTION:
Page 4 of 12
Drawing : - TPC305
Issue : - 7
Date : - 24/11/16
