Summary of Contents for EIP 11285ML-GB
- Page 1 Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 WM15 150 0 0 0 DEHUMIDIFIER DEHUMIDIFIER DEHUMIDIFIER DEHUMIDIFIER OWNER’S MANUAL www.eipl.co.uk Page 1 of 16...
-
Page 2: Safety Information
Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 SAFETY INFORMATION Children shall not play with the appliance. This appliance can be used by children from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the application in a safe way and understand the hazards involved. - Page 3 Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 The appliance uses R454c refrigerant gas. This gas is much kinder to the environment as it is non-toxic with zero Ozone Depletion Potential (ODP). This is a flammable gas and the following warnings should be considered: •...
- Page 4 Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 DEHUMIDIFIER PRINCIPLE Dehumidifiers remove moisture from the air that is circulating through the appliance. The resulting reduction of relative humidity helps prevent rust, rot, mould, mildew and condensation within the room, or other enclosed spaces where the dehumidifier is used.
-
Page 5: Installation
Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 INSTALLATION POSITIONING: The appliance can be left free standing and should be positioned in the center of the room to be conditioned if at all possible. If a damp patch is particularly apparent the outlet grille should be pointed towards it. - Page 6 Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 NOTE: Both inlet grille and outlet grille of the appliance must have clear space around them and not be obstructed in anyway. The unit must also be level whether free standing or wall mounted.
-
Page 7: Operation
Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 OPERATION Once the appliance is installed turn the power supply on, then turn the on / off switch to the ‘I’ position and note the unit starts. Then carry out the following: - •... - Page 8 Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 Light Functions: The unit has four LED indicators, located on the side of the unit. The following lists the functions of these lights: 1 - ON / OFF Green solid –...
-
Page 9: Routine Service
Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 ROUTINE SERVICE WARNING: ENSURE THE POWER CORD TO THE APPLIANCE IS DISCONNECTED BEFORE CARRYING OUT ROUTINE SERVICE. SERVICING AND REPAIR SHOULD ONLY BE CARRIED OUT BY A SUITABLY QUALIFIED PERSON. To ensure continued full efficiency of the appliance, maintenance procedures should be performed as follows: Clean the surface of the evaporator and condenser coils by blowing the... -
Page 10: Specifications
Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 SPECIFICATIONS : 11285ML-GB ODEL : 680 mm (26.7 in) EIGHT : 810 mm (31.9 in) IDTH : 305 mm (12 in) EPTH : 75 Kg (165.3 lb) EIGHT... - Page 11 Issue : - 2 Date : - 29/11/24 APPLIANCE SPARE PARTS LIST Description Part Number Product Part Number 11285ML-GB PCB Timer 1619522 Light Display PCB 1619523 PCB Connecting Cable 2013748 Humidistat Control Knob 2018644 Condenser Coil 2028400 Evaporator Coil 2028401...
- Page 12 Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 300mm 300mm 300mm 300mm Page 12 of 16...
- Page 13 Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 Page 13 of 16...
- Page 14 Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 Page 14 of 16...
- Page 15 Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 Page 15 of 16...
- Page 16 Drawing : - TPC552 Issue : - 2 Date : - 29/11/24 UK Head Office American Sales Office Ebac Industrial Products Ltd Ebac Industrial Products Inc St Helens Trading Estate 700 Thimble Shoals Blvd. Bishop Auckland Suite 109, Newport News County Durham Virginia, 23606-2575 DL14 9AD...
