- Page 1 Drawing : - TPC148 Issue : - 4 Date : - 24/11/16 DEHUMIDIFIER OWNER’S MANUAL www.eipl.co.uk Page 1 of 12...
- Page 2 Drawing : - TPC148 Issue : - 4 Date : - 24/11/16 UNPACKING Carefully remove the PP6 dehumidifier unit from its transit box and visually check for signs of transit damage. If there is evidence of damage DO NOT attempt to operate the unit, call your supplier for advice. Do not discard the packing;...
-
Page 3: Specifications
Drawing : - TPC148 Issue : - 4 Date : - 24/11/16 SPECIFICATIONS : PP6 ODEL : 256mm EIGHT : 300mm IDTH : 470mm EPTH : 25 Kg EIGHT : 7 M IRFLOW /min : 230V, 1 ph, 50Hz OWER UPPLY 350W (max) OWER... - Page 4 Drawing : - TPC148 Issue : - 4 Date : - 24/11/16 INSTALATION POSITIONING: Position the dehumidifier unit in the center of the room to be conditioned if at all possible. However if a damp patch is particularly apparent the outlet grille should be pointed towards it.
-
Page 5: Air Moving System
Drawing : - TPC148 Issue : - 4 Date : - 24/11/16 OPERATION The operation of the dehumidifier is to remove moisture from the air by having it condense on the cold tubes of the evaporator coil. The air then passes over the hot condenser coil and returns to the conditioned space slightly warmer and dryer than when it entered the dehumidifier unit. - Page 6 Drawing : - TPC148 Issue : - 4 Date : - 24/11/16 WARNING: • Due to the high pressures within the refrigeration circuit, under no circumstances must direct heat be applied to the evaporator coil in an attempt to remove the build up of ice. •...
-
Page 7: Routine Service
Drawing : - TPC148 Issue : - 4 Date : - 24/11/16 ROUTINE SERVICE WARNING: ENSURE THAT THE POWER CORD TO THE MACHINE HAS BEEN DISCONNECTED BEFORE CARRYING OUT ROUTINE SERVICE. THE SERVICING AND REPAIR OF THIS UNIT SHOULD ONLY BE CARRIED OUT BY A SUITABLY QUALIFIED PERSON. - Page 8 Drawing : - TPC148 Issue : - 4 Date : - 24/11/16 REPAIRS Should an electrical component fail, consult the Factory Service Center to obtain the proper replacement part. If refrigerant gas is lost from the machine, it will be necessary to use a refrigeration technician to correct the fault.
-
Page 9: Troubleshooting
Drawing : - TPC148 Issue : - 4 Date : - 24/11/16 TROUBLESHOOTING YMPTOM AUSE EMEDY 1. Tighten fan 1. Loose fan on shaft 2. Replace the fan motor 2. Fan motor burnt out 3. See Routine Maintenance 3. Dirty refrigeration coils Section Little or no airflow 4. -
Page 10: Spare Parts List
Drawing : - TPC148 Issue : - 4 Date : - 24/11/16 SPARE PARTS LIST ESCRIPTION UMBER Compressor 3022131 3021516 Compressor OH Protector Compressor Relay 3021517 Compressor Box Cover 3021518 Condenser Coil 3020740 Evaporator Coil 3014203 Filter Dryer 3020937 Fan Motor 3030194 Fan Blade 3040101... - Page 11 Drawing : - TPC148 Issue : - 4 Date : - 24/11/16 WARNINGS This appliance can be used by children from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the application in a safe way and understand the hazards involved.
