WOODBRIDGE
DIMENSIONS/TECHNICAL DATA
27-1/8"
ADA 17-3/8"
1 3/4"
7-7/8"
20"
21"
2-3/16"
2-3/8"
17"
2"
13"
3-1/4"
13"
ATTENTION!
Dimensions may vary by up to 3/8". It is highly recommended to pull
all dimensions of actual model for installation and measuring purposes.
