- Page 1 WOODBRIDGE ONE PIECE TOILET T0001 / B0940 MPN: INSTALLATION INSTRUCTIONS...
-
Page 2: Tools Required For Installation
ONE PIECE TOILET READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION. 2 PEOPLE ARE REQUIRED TO LIFT AND DURING ENTIRE INSTALLATION OF THIS PRODUCT INSTALLATION OF THIS PRODUCTS BY AN INEXPERIENCED INSTALLER MAY RESULT... -
Page 3: Dimensions/Technical Data
ONE PIECE TOILET DIMENSIONS/TECHNICAL DATA 28 1/2" 2 1/2" 14 1/4" 7 1/4" 2" 1 1/2" 18" 5 1/2" Rough-in 12" Standard ATTENTION! Dimensions may vary by up to 3/8". It is highly recommended to pull all dimensions of actual model for installation and measuring purposes. TECHNICAL DATA •... -
Page 4: Side View
ONE PIECE TOILET WATER SUPPLY LOCATION & TECHNICAL INFORMATION Side View Back View Threaded Shunk (Water Supply Fill Valve) Supply Posi on 1 15" Supply 3" Posi on 2 5 1/2" 5 1/2" Floor 12" 5 1/2" Rough-in 4 1/2" 12"... -
Page 5: Installation Instructions
ONE PIECE TOILET INSTALLATION INSTRUCTIONS IMPORTANT! Shut off main water supply prior to installation! REMOVE OLD TOILET 1. Shut off water supply line. If you do not have shut-off valve near the toilet shut off main water supply line. 2. Flush the old toilet and make sure that tank is empty. 3. - Page 6 ONE PIECE TOILET CAUTION! 2 PEOPLE ARE REQUIRED TO LIFT AND DURING ENTIRE INSTALLATION OF THIS PRODUCT INSTALL NEW TOILET Step 1. Lift and carefully put the toilet over the closet flange so the closet bolts can go through the mounting holes in the toilet's base.
- Page 7 ONE PIECE TOILET TOILET SEAT ADJUSTMENT...
-
Page 8: Base Installation
ONE PIECE TOILET ADJUSTMENT & MAINTENANCE (DUAL FLUSH VALVE) Important Note: Flush GPF amount is factory set. No addi onal adjustment is required. This page is for reference only. All adjustments are already made by manufacturer. 1. BASE INSTALLATION Gasket Check the dual flush Install the base with the Install a body of the flush... -
Page 9: Water Level Adjustment
ONE PIECE TOILET ADJUSTMENT & MAINTENACE (FILL VALVE) Important Note: Flush GPF amount is factory set. No addi onal adjustment is required. This page is for reference only. All adjustments are already made by manufacturer. Instructions: 95mm When valve installed, the critical level mark on fill valve (identified by C.L. - Page 10 ONE PIECE TOILET CLEANING & TROUBLESHOOTING (FILL VALVE) FILL VALVE CLEANING Shut off water supply line Carefully, take out the filter Use water to wash and clean Re-install the filter and before filter cleaning. from inlet by using pliers. the filter and adapter from any re-connect the water supply debris.
