INSTALLATION AND CARE GUIDE
ELECTRONIC WASHLET TOILET :B0990S
Compliance with the following codes & standard:
• 2015 Uniform Plumbing Code
• 2018 International Plumbing Code
• 2018 International Residential Code
• CSA B45.5 / IAPMO Z124-2017- Plastic Plumbing Fixtures
SCC Accredited
ICC
TM
LISTED
Accrédité
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time)
WOODBRIDGE
CB-P/S
ANSI
ACCREDITED
ISO/IEC 17065
OCPS
Product Certification Body
CCN
#1000
Or Email: help@woodbridgebath.com
www.woodbridgebath.com
R
®
( UPC )
®
( IPC )
®
( IPC )
PREFERED
EDUCATION
PROVIDER
20210703 REV. 1
Advertisement
Table of Contents
Related Manuals for Woodbridge B0990S
Summary of Contents for Woodbridge B0990S
- Page 1 INSTALLATION AND CARE GUIDE WOODBRIDGE ELECTRONIC WASHLET TOILET :B0990S Compliance with the following codes & standard: ® ( UPC ) • 2015 Uniform Plumbing Code ® ( IPC ) • 2018 International Plumbing Code ® ( IPC ) • 2018 International Residential Code •...
-
Page 2: Table Of Contents
Content WOODBRIDGE Safety instructions Technical specification List of materials Technical drawings Parts identification Toilet Installation Previous preparation Auto cover open/close Sensor foot Daily maintenance 1.Main unit care and maintenance 2.Spray nozzle maintenance and care 3.Maintenance of filter net Emergency troubleshooting 1.Electricity and water cut off... - Page 3 IMPORTANT SAFEGUARDS WOODBRIDGE When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: 1.The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
-
Page 4: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION – Indicates that failure to follow the instruction may cause body injury or property damage. 1. Do not install or use the product in wet places as steam room etc. 2. It is recommended to use water-proof electrical outlet which should be lnstalled in the place where is not easily got wet. -
Page 5: Technical Specification
Technical Specification WOODBRIDGE Model B0990S Rated voltage 110V-120V,50/60Hz Rated power 1170W Main Unit Overall unit Waterproof IPX4 Electrical wire Length is about 2.2m Flush volume 1.6/1.1Gpf（full flush6.0L/half flush4.1L） Flushing mode Siphonic jet Rough-in distance 12" Toilet Outlet outside diameter ≤100mm... - Page 6 WOODBRIDGE Model B0990S Deodorization Deodorization Method Non-photocatalyst Deodorization Surface temperature 6 different level adjustment Heating power Heated burning Heated seat The seat temperature will automatically lower to level 1 in 10 minutes after using protection Sensed area,Temperature senor,Thermal fuse, Safety device...
-
Page 7: List Of Materials
Main Unit Remote controller components Sealing Flange Installation Cardboard INSTALLATION AND CARE GUIDE WOODBRIDGE ELECTRONIC WASHLET TOILET :B0990S Compliance with the following codes & standard: ® • 2015 Uniform Plumbing Code ( UPC ) • 2018 International Plumbing Code ®... -
Page 8: Technical Drawings
Technical drawing WOODBRIDGE 27 1/2" 1.The product drawing is for reference only, and we reserve the right to modify the appearance of the product. 2.If the appearance of the product is changed, the actual product shall prevail. www.woodbridgebath.com... -
Page 9: Parts Identification
Parts identification WOODBRIDGE Left side Bumper Display button Seat Ceramic toilet Right side Spray rod baffle Warm-air baffle Rear Front Remote cleaning cleaning sensing window Spray nozzle Use the foot to touch the sensing area www.woodbridgebath.com... -
Page 10: Toilet Installation
Installation of ceramic toilet WOODBRIDGE 3.Hose Precaution before installing Minimum dynamic working water pressure: Connect the water inlet and angle valve of the 0.09MPa or more (3.96Gal/min(15L/min) or toilet with the matching hose and tighten it more), failure to meet this pressure will not achieve the best flushing effect. - Page 11 WOODBRIDGE 5.Ceramic toilet installation 6.Screw installation Install sealing flange into drain outlet; Put the screw through the fixing sleeve and then install it through the holes(on both sides Install ceramic toilet on corresponding of the toilet ceramic) to the mounting bracket position according to contour line.
-
Page 12: Previous Preparation
Previous preparation WOODBRIDGE 1. Turn on the angle valve Check thread connection, make sure no leakage is found,unscrew angle valve anticlockwise to maximum opening. (Tips: When opening for the first time, the angle valve handle has a larger torque) Angle valve 2.Power Connection... -
Page 13: Auto Cover Open/Close
Auto cover open/close WOODBRIDGE The intelligent toilet can achieve the function of auto cover open/close.is on closed situation, so please start the auto cover open/close function by using remote controler. 1.Approaching the toilet Cover When approaching the toilet, the mechanism will detect the movement and the cover will open automatically. -
Page 14: Sensor Foot
Sensor foot WOODBRIDGE The toilet is equipped with foot sensor cover-open function, it can make cover auto-open by sensing foot movement. 1.When the cover and seat are both closed, put the foot within the sensing area and then cover opens automatically. -
Page 15: Daily Maintenance
Daily maintenance WOODBRIDGE Spray nozzle maintenance and care Main unit care and maintenance 1. Shut off power supply before doing 1. Nozzle self-cleaning maintenance. While not sitting on the unit, short press the “ REAR/MOVE ” Button on the main unit, the spray nozzle will extend outward and water will flow out. -
Page 16: Maintenance Of Filter Net
Emergency Troubleshooting WOODBRIDGE Maintenance of filter net Electricity and water cut off Time for maintenance: It is under Put around 2.1Gal (8L) water into a barrel and flush the bowl. normal water pressure but poor flush performance occurs. Note: Avoid water spilling from bowl. -
Page 17: Failure Of Remote Control
WOODBRIDGE When the product is left unused for Failure of remote control long time 1.Operate through the toilet body button When no one at home for a long time, please drain out the water inside tank and pipe to prevent freezing. -
Page 18: Description Of The Button Function
WOODBRIDGE Description of the button function 1. Press and hold the “Stop” button on the unit, the unit enters the shutdown mode (white light off), press the “Stop” button again, the unit returns to the working mode (White light normally on).[In the shutdown mode, except for the “Stop”... -
Page 19: Display Led Description
Display LED description WOODBRIDGE intelligent water temperature temperature display seat temperature ECO energy saving night light Description of display LED light: 1.During the power on self-test stage, the icons of intelligent night light, water temperature, seat temperature and ECO are all on, and the temperature is displayed at 88 ℉. -
Page 20: Troubleshooting Guide
Troubleshooting Guide WOODBRIDGE Problem Cause Solution Water supply hose buckling Solve the buckling causes block No flushing Turn on the fill valve Fill valve is off Connect water supply and Water supply is cut off wait for the water Water supply hose buckling... - Page 24 Thank you for using WoodBridge products! Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help@woodbridgebath.com www.woodbridgebath.com ASVFA72610003A-1.0...
