INSTALLATION AND CARE GUIDE
ELONGATED TOILET : T0033/B0933
Compliance with the following codes & standard:
• 2015 Uniform Plumbing Code
• 2018 International Plumbing Code
• 2018 International Residential Code
• CSA B45.5 / IAPMO Z124-2017- Plastic Plumbing Fixtures
SCC Accredited
ICC
TM
LISTED
Accrédité
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time)
WOODBRIDGE
CB-P/S
ANSI
ACCREDITED
ISO/IEC 17065
OCPS
Product Certification Body
CCN
#1000
Or Email: help@woodbridgebath.com
www.woodbridgebath.com
R
( UPC )
®
( IPC )
®
®
( IPC )
PREFERED
EDUCATION
PROVIDER
20200623 REV. 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T0033 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Woodbridge T0033

  • Page 1 INSTALLATION AND CARE GUIDE WOODBRIDGE ELONGATED TOILET : T0033/B0933 Compliance with the following codes & standard: ( UPC ) ® • 2015 Uniform Plumbing Code ( IPC ) ® • 2018 International Plumbing Code ® ( IPC ) • 2018 International Residential Code •...
  • Page 2: Tools Required For Installation

    WOODBRIDGE ELONGATED TOILET READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION. 2 PEOPLE ARE REQUIRED TO LIFT AND DURING...
  • Page 3 WOODBRIDGE ELONGATED TOILET 26 3/4" 14" 6 1/2" 1 1/8" 18" Rough-in 12" Standard IMPORTANT INFORMATION • Measurements are +3/8" and subject to change without no ce • Please note that installer(s) must be cer fy or warranty will be voided.
  • Page 4: Side View

    WOODBRIDGE ELONGATED TOILET WATER SUPPLY LOCATION & TECHNICAL INFORMATION Side View Back View Threaded Shunk (Water Supply Fill Valve) Floor Rough-in 12" Standard Side View Tank Top View (Inside) Full Half Flush Flush (1.6GPF) (1GPF) Adjust the water level in the...
  • Page 5: Installation Instructions

    WOODBRIDGE ELONGATED TOILET INSTALLATION INSTRUCTIONS IMPORTANT! Shut off main water supply prior to installation! REMOVE OLD TOILET 1. Shut off water supply line. If you do not have shut-off valve near the toilet shut off main water supply line. 2. Flush the old toilet and make sure that tank is empty.
  • Page 6 WOODBRIDGE ELONGATED TOILET CAUTION! 2 PEOPLE ARE REQUIRED TO LIFT AND DURING ENTIRE INSTALLATION OF THIS PRODUCT INSTALL NEW TOILET Step 1. Lift and carefully put the toilet over the closet flange so the closet bolts can go through the mounting holes in the toilet's base.
  • Page 7 WOODBRIDGE ELONGATED TOILET TOILET SEAT ADJUSTMENT Hinge set Seat and cover Insert the hinges into the toilet Tighten the screws of the hinges Untighten the screws a bit by turn- ing them 90° right Clip on the toilet seat and cover...
  • Page 8: Base Installation

    WOODBRIDGE ELONGATED TOILET ADJUSTMENT & MAINTENANCE (DUAL FLUSH VALVE) Important Note: Flush GPF amount is factory set. No addi onal adjustment is required. This page is for reference only. All adjustments are already made by manufacturer. 1. BASE INSTALLATION Gasket...
  • Page 9: Water Level Adjustment

    WOODBRIDGE ELONGATED TOILET ADJUSTMENT & MAINTENACE (FILL VALVE) Important Note: Flush GPF amount is factory set. No addi onal adjustment is required. This page is for reference only. All adjustments are already made by manufacturer. Instructions: 95mm When valve installed, the critical level mark on fill valve (identified by C.L.
  • Page 10 Note: fill and flush valves are maintenance free. No maintenance is required. Retain these installa on instruc ons for future reference! Thank you for using WoodBridge products! Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help@woodbridgebath.com...
