INSTALLATION AND CARE GUIDE
ELECTRONIC WASHLET TOILET :V8300/B0950S
Compliance with the following codes & standard:
• 2015 Uniform Plumbing Code
• 2018 International Plumbing Code
• 2018 International Residential Code
• CSA B45.5 / IAPMO Z124-2017- Plastic Plumbing Fixtures
SCC Accredited
ICC
TM
LISTED
Accrédité
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time)
WOODBRIDGE
CB-P/S
ANSI
ACCREDITED
ISO/IEC 17065
OCPS
Product Certification Body
CCN
#1000
Or Email: help.woodbridge@gmail.com
www.woodbridgebath.com
R
®
( UPC )
®
( IPC )
®
( IPC )
PREFERED
EDUCATION
PROVIDER
110518 REV. 1
Advertisement
Table of Contents
Related Manuals for Woodbridge V8300
Summary of Contents for Woodbridge V8300
- Page 1 INSTALLATION AND CARE GUIDE WOODBRIDGE ELECTRONIC WASHLET TOILET :V8300/B0950S Compliance with the following codes & standard: ® ( UPC ) • 2015 Uniform Plumbing Code ® ( IPC ) • 2018 International Plumbing Code ® ( IPC ) • 2018 International Residential Code •...
-
Page 2: Tools Required For Installation
WOODBRIDGE ELECTRONIC WASHLET TOILET READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION. 2 PEOPLE ARE REQUIRED TO LIFT AND DURING... -
Page 3: Important Safeguards
WOODBRIDGE ELECTRONIC WASHLET TOILET IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions shouldalways be followed, including the following: 1.The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. -
Page 4: Grounding Instructions
WOODBRIDGE ELECTRONIC WASHLET TOILET CAUTION – Indicates that failure to follow the instruction may cause body injury or property damage. 1. Do not install or use the product in wet places as steam room etc.This product must be connected to properly grounded power outlet socket. - Page 5 WOODBRIDGE ELECTRONIC WASHLET TOILET Rating pressure AC 110V-120V,50/60Hz Rating power 1200W-1400W Main Unit Water pressure Minimum water pressure 0.07MPa (20L/min. flow). range Maximum water pressure 0.8MPa (Hydrostatic pressure) Electrical wire length is about 1.8m Flush volume 1.6/1.1GPF(6.0/4.0 L) Flushing mode...
-
Page 6: Dimensions/Technical Data
WOODBRIDGE ELECTRONIC WASHLET TOILET DIMENSIONS/TECHNICAL DATA 15 3/8" 20 3/4" 17 7/8" 22 5/8" 16" IMPORTANT INFORMATION • Measurements are +3/8" and subject to change without notice • Please note that installer(s) must be certify or warranty will be voided. -
Page 7: Parts Identification
WOODBRIDGE ELECTRONIC WASHLET TOILET PARTS IDENTIFICATION Bumper Left side Power indicator Energy saving indicator Human body sensing window Human body Remote sensing window sensing window Rear cleaning button Seat Drying button Power button Ceramic toilet Flush button Front cleaning button... - Page 8 WOODBRIDGE ELECTRONIC WASHLET TOILET Installation of ceramic toilet 1.Water supply angle valve installation 3.Ceramic toilet installtion •Draw drain outlet centerline on the floor, •Install sealing flange into drain outlet， Install angle valve at proper position on without bolts fixation; wall according to dimension of toilet.
- Page 9 WOODBRIDGE ELECTRONIC WASHLET TOILET 5.Installation of hose •Connect water inlet and angle valve by new hose. Note: Recommend strongly to install floor fixing bolt!lt can make product more stable to avoid damage of toilet or toilet or personal injury because of shifting or turning over by misusing(squat or stand on toilet).
- Page 10 WOODBRIDGE ELECTRONIC WASHLET TOILET Previous preparateion 1.Turn on the angle valve Check thread connection,make sure no leakage is found. Angle valve 2.Switch the power supply Grounded Insert electric leakage protection plug into power socket. outlet Indicator light Electric leakage test button...
-
Page 11: Daily Maintenance
WOODBRIDGE ELECTRONIC WASHLET TOILET Daily maintenance Main unit care and maintenace Spray nozzle maintenance and care 1.Shut off power supply at maintenance. 1.Nozzle self-cleaning Press “nozzle cleaning” button and nozzle will move forward and self-clean. 2.Turn the seat upward open,... -
Page 12: Emergency Troubleshooting
WOODBRIDGE ELECTRONIC WASHLET TOILET Emergency Troubleshooting Electricity and water supply cut-off 1. Power failure •Manually press button of full/half flush to perform the toilet flushing. Operation panel 2.Water failure •Put around 8L water into a barrel and flush the bowl of ceramic. - Page 13 WOODBRIDGE ELECTRONIC WASHLET TOILET Failure of remote control When the product is left unused for long time 1.Operate the panels on ebidet seat to perform. •Especially in winter season,the water inside the tank should be discharged to avoid freezing. To discharge water 1.Turn off the water supply angle valve...
- Page 14 WOODBRIDGE ELECTRONIC WASHLET TOILET The illustration of main unit keys 1. Long press "power" button to enter standby mode; and then quick press "power" button to restore functional mode. Power 2. When people sit, press "power" button to stop the function of rear, front cleaning or drying.
-
Page 15: Troubleshooting Guide
WOODBRIDGE ELECTRONIC WASHLET TOILET Troubleshooting Guide Problem Cause Solution water supply hose buckling solve the buckling causes block No flushing turn on the fill valve fill valve is off Connect water supply and Water supply is cut off wait for the water... - Page 16 The purchasing dte is subject to the purchasing invoice or receipt. Please keep this warranty and invoice/receipt available for repair or maintenance. Thank you for using WoodBridge products! Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help.woodbridge@gmail.com...
