INSTALLATION MANUAL B0970S
R
WOODBRIDGE
ELECTRONIC WASHLET TOILET
Installation Manual
● Thank you for choosing our products.Please read the instructions carefully before
installation and keep it available for future maintenance or reference.
●Our company reserves the right of final interpretation for this manual.
The manual is subject to change without notice.
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time)
Or Email: help@woodbridgebath.com
202056 REV. 1
www.woodbridgebath.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Woodbridge B0970S
Summary of Contents for Woodbridge B0970S
- Page 1 INSTALLATION MANUAL B0970S WOODBRIDGE ELECTRONIC WASHLET TOILET Installation Manual ● Thank you for choosing our products.Please read the instructions carefully before installation and keep it available for future maintenance or reference. ●Our company reserves the right of final interpretation for this manual.
-
Page 2: Important Safeguards
WOODBRIDGE IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions shouldalways be followed, including the following: 1.The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. -
Page 3: Important Safety Instructions
WOODBRIDGE IMPORTANT SAFETY INSTRUCTIONS CAUTION – Indicates that failure to follow the instruction may cause body injury or property damage. 1. Do not install or use the product in wet places as steam room etc.This product must be connected to properly grounded power outlet socket. -
Page 4: Technical Specification
WOODBRIDGE TECHNICAL SPECIFICATION Model B0970S Rating pressure 110V-120V,50/60Hz Rating power 1200W-1400W Overall unit IPX4 Waterproof Main Unit Electrical wire length is about 1.5m Flush volume 4.8L（full flush6.0L/half flush4.2L） Flushing mode Siphonic jet Rough-in Toilet 12" 15 3/4" distance Outlet outside 3 1/2"... - Page 5 WOODBRIDGE Model B0970S Deodorization Deodorization Diatoms Deodorization Method Surface 6 different level adjustment temperature Heating power Open and close Quiet soft-closing device,Auto open and close device Heated seat Heated burning The seat temperature will automatically lower to level protection 1 in 10 minutes after using...
-
Page 6: List Of Materials
WOODBRIDGE LIST OF MATERIALS Remote controller components Main Unit Sealing Flange Installation Cardboard Model E2-B1 E2-F1 Installation Manual Thank you for choosing our products.Please rea the instructions carefully before installation and keep it available for future maintenance or refere. Our company reserves the right of final interpretation for this manual. -
Page 7: Technical Drawing
WOODBRIDGE TECHNICAL DRAWING 27 1/4" The product drawing is for reference only, and we reserve the right to modify the appearance of the product. www.woodbridgebath.com... -
Page 8: Parts Identification
WOODBRIDGE PARTS IDENTIFICATION Bumper Left side Rear cleaning button Seat Front cleaning button Flush Ceramic toilet Stop Right side Drying baffle Rear cleaning Remote Front sensing cleaning window Spray nozzle www.woodbridgebath.com... - Page 9 WOODBRIDGE INSTALLATION OF CERAMIC TOILET Precaution before installing Minimum dynamic working water pressure: 0.09MPa or more (15.0L/min or more), failure to meet this pressure will not achieve the best flushing effect. 2 3/4” Remark: Apply the methods below if you don’t have water pressure testing device.
- Page 10 WOODBRIDGE 4.Ceramic toilet installtion 5.Glass cement application Install sealing flange into drain outlet; Apply high quality mildew glass glue around the lower edge of the toilet. Install ceramic toilet on corresponding position according to contour line. Glass Cement Toilet drain outlet...
- Page 11 WOODBRIDGE PREVIOUS PREPARATEION 1. Turn on the angle valve Check thread connection, make sure no leakage is found,unscrew angle valve anticlockwise to maximum opening. (Tips: When opening for the first time, the angle valve handle has a larger torque) Angle valve 2.
-
Page 12: Daily Maintenance
WOODBRIDGE DAILY MAINTENANCE Spray nozzle maintenance and care Main unit care and maintenace 1. Nozzle self-cleaning 1. Shut off power supply at maintenance. When no user is seated, press the “rear cleaning button” on the main unit to start nozzle self-cleaning manually, the nozzle will automatically moves forward and clean itself with water. -
Page 13: Emergency Troubleshooting
WOODBRIDGE EMERGENCY TROUBLESHOOTING Maintenance of filter net No water supply Time for maintenance: It is under normal water pressure but poor Put around 8L water into a barrel and flush performance occurs. flush the bowl of ceramic. Note: Avoid water spilling from bowl. - Page 14 WOODBRIDGE When the product is left unused for Failure of remote control long time Operate through the toilet body knob Especially in winter when no one at home for a long time, please drain out the water inside tank and pipe to prevent freezing.
- Page 15 WOODBRIDGE THE ILLUSTRATION OF MAIN UNIT KEYS The illustration of main unit buttons 1. Press and hold the “Stop” button （ for about 3s ） on the unit, the unit enters the shutdown mode (red light off), press the “stop button”...
-
Page 16: Troubleshooting Guide
WOODBRIDGE TROUBLESHOOTING GUIDE Problem Cause Solution Water inlet hose bent to Solve the problem of bending cause blocking of water inlet hose No Water from Turn on the inlet valve Inlet valve is off Nozzle Connect water supply and Water supply is cut off...
