INSTALLATION AND CARE GUIDE
ELECTRONIC WASHLET TOILET :B0980S
Compliance with the following codes & standard:
• 2015 Uniform Plumbing Code
• 2018 International Plumbing Code
• 2018 International Residential Code
• CSA B45.5 / IAPMO Z124-2017- Plastic Plumbing Fixtures
SCC Accredited
ICC
TM
LISTED
Accrédité
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time)
WOODBRIDGE
CB-P/S
ANSI
ACCREDITED
ISO/IEC 17065
OCPS
Product Certification Body
CCN
#1000
Or Email: help@woodbridgebath.com
www.woodbridgebath.com
R
®
( UPC )
®
( IPC )
®
( IPC )
PREFERED
EDUCATION
PROVIDER
20201020 REV. 1
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Woodbridge B0980S
Summary of Contents for Woodbridge B0980S
- Page 1 INSTALLATION AND CARE GUIDE WOODBRIDGE ELECTRONIC WASHLET TOILET :B0980S Compliance with the following codes & standard: ® ( UPC ) • 2015 Uniform Plumbing Code ® ( IPC ) • 2018 International Plumbing Code ® ( IPC ) • 2018 International Residential Code •...
-
Page 2: Table Of Contents
Content WOODBRIDGE Safety instructions Technical specification List of materials Technical drawings Parts identification Installation of ceramic toilet Previous preparation Auto lid open/close Daily maintenance 1.Main unit care and maintenace 2.Spray nozzle maintenance and care 3.Maintenance of filter net Emergency troubleshooting 1.Electricity and water supply cut-off... -
Page 3: Safety Instructions
Safety instructions WOODBRIDGE Please read the instructions carefully before installation and keep it available for future maintenance or reference. Failure to observe this instruction can cause body injury and property damage. Symbol lllustration Indicates that failure to follow the instruction may cause serious Warning injury or a fatal. - Page 4 Warning This product should be used with 110V, 50Hz electrical current only, load current is at least 13A. Power plug must be equipped with ground fault circuit interrupter or ground fault electrical leakage protector or similar high sensitive, rapid type leakage switch (Rated sensitive current under 6mA).
-
Page 5: Technical Specification
Technical specification WOODBRIDGE Rating pressure 110V,50Hz Rating power 1120W Overall unit IPX4 Waterproof Main Unit Water pressure Minimum water pressure 0.08MPa range Maximum water pressure 0.8MPa Electrical wire length is about 2.2m Average flush 1.28GPF( Full flush 1.6G/Half flush 1.1G）... - Page 6 WOODBRIDGE Surface 6 different level adjustments temperature Heating power Heated seat Heated burning The seat temperature will automatically decrease to level protection 1 in 10 minutes after using Sensed area,Temperature senor,Thermal fuse, Safety device Bimetal thermostat,Leakage protection plug Night light...
-
Page 7: List Of Materials
List of materials WOODBRIDGE Main Unit Remote controller components Sealing Flange Installation Cardboard Installation Manual Warranty Card Flange Angle Valve Hose Mounting accessory kit www.woodbridgebath.com... -
Page 8: Technical Drawings
Technical drawing WOODBRIDGE 27 1/2" 16" 1.The product drawing is for reference only, and we reserve the right to modify the appearance of the product. 2.If the appearance of the product is changed, the actual product shall prevail. www.woodbridgebath.com... -
Page 9: Parts Identification
Parts identification WOODBRIDGE Bumper Left side Flush Seat Front cleaning button Rear cleaning Porcelain Bowl button Stop/ECO Drying baffle Rear cleaning Front cleaning Power cord Spray nozzle Manual flush button Deodorization window Right side Remote sensing window Touch the sensing area with your foot (optional) www.woodbridgebath.com... -
Page 10: Installation Of Ceramic Toilet
Installation of ceramic toilet WOODBRIDGE 1. Installation of mating angle valve 3.Connect flexible hose to water inlet Draw drain outlet centerline on the floor, Connect one end of new hose to water inlet Install angle valve at proper position on and tighten it. - Page 11 WOODBRIDGE 5. Porcelain toilet installation 7. Connect hose to angle valve Install sealing flange into drain outlet. Connect other end of new hose to angle valve Install ceramic toilet on corresponding and tighten it. position according to contour line. Toilet drain outlet Sealing flange 8.
-
Page 12: Previous Preparation
Previous preparation WOODBRIDGE 1. Turn on the angle valve Check thread connection, make sure no leakage is found, unscrew angle valve anticlockwise to maximum opening. (Tips: When opening for the first time, the angle valve handle has a larger torque) Angle valve 2.Power Connection... -
Page 13: Auto Lid Open/Close
Auto lid open/close WOODBRIDGE If you purchase the intelligent toilet with auto lid open/close function, the product can achieve the function of auto lid open/close. The factory default of this function is on closed situation, so please start the auto lid open/close function by using remote. -
Page 14: Daily Maintenance
Daily maintenance WOODBRIDGE Main unit care and maintenace Spray nozzle maintenance and care 1. Nozzle self-cleaning 1. Shut off power supply at maintenance. When no user is seated, press the “Rear Wash/massage” button on the main unit, the nozzle will automatically extend and flow out the washing water. -
Page 15: Maintenance Of Filter Net
Emergency troubleshooting WOODBRIDGE Maintenance of filter net Electricity and water supply cut-off Time for maintenance: It is under 1. No power normal water pressure but poor flush performance occurs. Activate flushing by pressing flush button manually . 1. Unscrew angle valve nut... -
Page 16: Failure Of Remote Control
WOODBRIDGE When the product is left unused for Failure of remote control long time 1. Operate the panels on Smart bidet seat Especially in winter when no one at home for a long time, please drain out the water inside tank and pipe to prevent freezing. -
Page 17: The Illustration Of Main Unit Keys
The illustration of Main Unit Keys WOODBRIDGE The illustration of main unit buttons 1. Press and hold the “Stop” button on the unit, the unit enters the shutdown mode (red light off), press the “stop button” again, the unit returns to the working mode (lights red).[In the shutdown mode, except for the “Stop”... -
Page 18: Troubleshooting Guide
Troubleshooting Guide WOODBRIDGE Problem Cause Solution Water inlet hose bent to Solve the problem of bending cause blocking of water inlet hose No water from Inlet valve is off Turn on the inlet valve Nozzle Connect water supply and Water supply is cut off... -
Page 19: Warranty Card
Product Warranty Card WOODBRIDGE Date of Purchased: Distributor Distributor Phone One(1) years Our company three www.woodbridgebath.com... - Page 20 Thank you for using WoodBridge products! Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help@woodbridgebath.com www.woodbridgebath.com ASVFAF0321011A-1.0...
