Specifications

Model
Operation method
Main fluid: Suction/Discharge port
Port
size
Pilot air: Supply/Exhaust port
Discharge flow rate
Average discharge pressure
Pilot air pressure
Air consumption
Dry
Suction
lift
Wet
Noise
Withstand pressure
Service life
Operating fluid temperature
Ambient temperature
Recommended operation cycle
Weight (without foot bracket)
Mounting
Packaging
Note) Values in the table are measured at room temperature using clean water.
Automatically Operated Type
PAF3410
Automatically operated
Rc, G, NPT 3/8" female thread, 1/2" tube extension
Rc, G, NPT 1/4"
1 to 20 l/min Note)
0.2 to 0.5 MPa (for 0 to 60°C)
230 l/min (ANR) or less
Up to 1 m (inside the pump is dry)
Up to 4 m (with fluid inside the pump)
80 dB (A) or less
(Option: with silencer, AN200)
50 million cycles (for water)
0 to 90°C (with no freezing)
0 to 70°C (with no freezing)
—
1.6 kg
Horizontal (mounting on the bottom surface)
Clean double packaging
Process Pump
Series
PAF3413
Air operated
Rc, G, NPT 1/8"
1 to 15 l/min
0 to 0.4 MPa
80 dB (A) or less
(excluding the noise from the quick exhaust
and solenoid valve)
0.75 MPa
2 to 4 Hz
1.3 kg
PAF
Note)
3
