- Page 1 Doc. no. PAB-OM-E001-F PRODUCT NAME Process Pump MODEL / Series / Product Number PA(P)3310 Series...
-
Page 2: Table Of Contents
Contents Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -P.2 to 3 Names and functions of parts - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P.4 Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P.5 to 9 Applicable Fluids - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P.10... -
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International ... - Page 4 Safety Instructions Caution 1.The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
-
Page 5: Names And Functions Of Parts
Names and functions of parts Reset button Air operated reset port Discharge port FLUID OUT Pilot air supply port AIR SUP Pilot air exhaust port Suction port AIR EXH FLUID IN Foot (Option) Description Functions Suction port (FLUID IN) Sucks the fluid to be transferred. Connect suction piping. Discharge port (FLUID Discharges the fluid taken in the pump. -
Page 6: Precautions
Precautions 1. Precautions for system design Warning 1. Confirm the specifications. - Give careful consideration to operating conditions such as the application, fluid and environment, and use the product within the operating ranges specified in this catalog. - The product is provided for physical, chemical and industrial equipment. 2. - Page 7 9. The pump cannot transfer gas. Do not allow it to idle for a long time. If the pump is operated for a long time without any fluid inside or in a gas-fluid mixed state, the diaphragm may be damaged or the life may be shortened. Do not continue idling for 3 minutes or longer.
- Page 8 3. Tighten screws with proper tightening torque. When screwing fittings into the product, tighten them with proper tightening torque as shown below. Looseness can cause problems such as fluid and air leaks, while over tightening can cause damage to threads and parts, etc. Connection thread Proper tightening torque (N·m) Rc, NPT, G, PNTF 1/4”...
- Page 9 6. Maintenance Warning 1. Perform maintenance after consulting the operation manual. Obtain the operation manual for the equipment from SMC or our distributor and have sufficient knowledge of the equipment before performing maintenance. Incorrect handling may cause damage or malfunction of the equipment or system. 2.
- Page 10 3. Please understand the following concerning the inability to repair the product. To enable the process pump to be used with various fluids, please note that from the aspects of ensuring worker safety and also the facilities, SMC is unable to carry out repair. 7.
-
Page 11: Applicable Fluids
Applicable Fluids Material and Fluid Compatibility Check List for Process Pumps - The data below is prepared based on data provided by the material manufacturers. - SMC assumes no responsibility for the accuracy of the data or for any damages arising from the data. -
Page 12: Specifications
Specifications Model PA3310 PAP3310 Actuation Automatically operated Rc, NPT, G, NPTF 3/8" Female thread Main fluid Rc, NPT, G, NPTF 3/8" 3/8", 1/2" Tube extension suction Female thread With nut (size 3, 4, 5) discharge port Port size 3/8", 1/2" Integrated fitting type Pilot air supply/exhaust Rc, NPT, G, NPTF 1/4"... -
Page 13: Performance Curve
Performance Curve Flow Rate Characteristics Air Consumption Selection from Flow Rate Characteristic Graph (PA(P)3310) Required specifications example: Find the pilot air pressure and pilot air consumption for a discharge rate of 6 L/min and a discharge pressure of 0.25 MPa. <The transfer fluid is fresh water (viscosity 1 mPa·s, specific gravity 1.0). ... - Page 14 Viscosity Characteristics (Flow rate correction for viscous fluids) Selection from Viscosity Characteristic Graph Required specifications example: Find the pilot air pressure and pilot air consumption for a discharge rate of 2.7 L/min, and a viscosity of 100 mPa·s. Selection procedures: 1.
-
Page 15: Working Principle
Working Principle Air exhaust port (AIR EXH) Switching valve Air supply port (AIR SUP) Pilot valve B Pilot valve A Discharge port (FLUID OUT) Pump chamber A Pump chamber B Check valve Shaft Suction port (FLUID IN) Diaphragm A Diaphragm B Drive chamber A Drive chamber B Control unit... -
Page 16: Piping And Operation
Piping and Operation Caution Mounting posture of the pump is set with the mounting foot facing downward. Air to be supplied to the air supply port <AIR SUP> should be cleaned and filtered through AF filter, etc. Air with foreign matter or drainage etc. -
Page 17: Dimensions
Dimensions Integrated fitting type With nut Tube extension... - Page 18 Revision 24-Sep-2019 Revision F - Completely revised by format change. 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
