- Page 1 Doc. no. PAB****-OMY0027 PRODUCT NAME Process Pump MODEL / Series / Product Number PA5013...
-
Page 2: Table Of Contents
Contents Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -P.2 to 3 Names and functions of parts - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P.4 Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -P.5 to 9 Applicable Fluids - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P.10... -
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International ... - Page 4 Safety Instructions Caution 1.The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
-
Page 5: Names And Functions Of Parts
Names and functions of parts Discharge port < FLUID OUT > Pilot air supply port : P1 < AIR SUP > Pilot air exhaust port Suction port : P2 < AIR SUP > <FLUID IN > Foot Description Functions Suction port Sucks the fluid to be transferred. -
Page 6: Precautions
Precautions 1. Caution on design Warning 1. Confirm the specifications. - Give careful consideration to operating conditions such as the application, fluid and environment, and use the product within the operating ranges specified in this catalog. - The product is provided for physical, chemical and industrial equipment. 2. - Page 7 11. Condensation and freezing of the pilot port The air supply port of the air operated type can cool down quickly due to expansion of the supply air, and this may cause condensation on the piping and the condensation may freeze during operation in winter.
- Page 8 4. Air Supply Warning 1. Use clean air. Do not use compressed air that includes chemicals, synthetic oils containing organic solvents, salinities or corrosive gases, etc., as it can cause damage or malfunction. 2. Pay attention to avoid freezing when operating the product in low temperatures. The equipment operates while expanding the compressed air.
- Page 9 Method per cycle A in service life B (wetted part) Automatically PA5013 PTFE Approx. 0.09L 50 million cycles Approx. 505 mL operated type 3. Please understand the following concerning the inability to repair the product. To enable the process pump to be used with various fluids, please note that from the aspects of...
- Page 10 7. Lubrication Caution 1. Do not lubrication. 8. Caution on Handling Warning 1. Test before using with the actual equipment. Test the pump before using it with the actual equipment. Even if there is no problem in a short-term test, the liquid may penetrate through the fluoropolymer diaphragm causing malfunction in the pump air circuit.
-
Page 11: Applicable Fluids
7. These may be penetrated by fluids, and the penetrating fluids may affect parts of other materials. Table symbols ○: Can be used. ×: Cannot be used. －: Can be used under certain conditions. Please consult us. Model PA5013 Body material Diaphragm material PTFE ○... -
Page 12: Specifications
Specifications Model PA5013-□04 PA5013-□06 Actuation Automatically operated Main fluid Rc, NPT, G, Female thread suction 1/2” 3/4" discharge port Port size Pilot air supply/exhaust Rc, NPT, G 1/4" Female thread port Body wetted areas Diaphragm PTFE Material Check valve PTFE, PP, PFA... -
Page 13: Performance Curve
Performance Curve Flow Rate Characteristics PA5010-□04 PA5010-□06 Selection from Flow Rate Characteristic Graph Required specifications example: Find the pilot air pressure and pilot air consumption for a discharge rate of 15 L/min and a discharge pressure of 0.14 MPa. <The transfer fluid is fresh water (viscosity 1 mPa·s, specific gravity 1.0). ... - Page 14 Air Consumption Calculating Air Consumption Find the air consumption of pilot air for operation with a 4 Hz switching cycle and pilot air pressure of 0.4 MPa from the air consumption graph. Selection procedures: 1. Look up from the 4 Hz switching cycle to find the intersection with SUP = 0.4 MPa. 2.
- Page 15 Viscosity Characteristics Selection from Viscosity Characteristic Graph Required specifications example: Find the pilot air pressure and pilot air consumption for a discharge rate of 12 L/min, and a viscosity of 100 mPa·s. Selection procedures: 1. First find the ratio of the discharge rate for fresh water when viscosity is 100 mPa·s from the graph above.
-
Page 16: Working Principle
Working Principle Air supply (AIR SUP) 5 port solenoid valves Discharge port (FLUID OUT) Pump chamber A Pump chamber B Check valve Shaft Suction port (FLUID IN) Diaphragm B Diaphragm A Drive chamber B Drive chamber A 1. When air is supplied to P1 port, it enters drive chamber A. 2. -
Page 17: Piping And Operation
Piping and Operation Caution Mounting posture of the pump is set with the mounting foot facing downward. Maintain the proper tightening torque for fittings and mounting bolts, etc. Looseness can cause problems such as fluid and air leaks, while over tightening can cause damage to threads and parts, etc. Starting and Stopping Refer to circuit example (1) Note 1) 1. -
Page 18: Dimensions
Dimensions... - Page 19 Revision 19-Feb-2021 Initial release 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
