Summary of Contents for SMC Networks PA3113
- Page 1 Document No. PAB-OM-C006-C PRODUCT NAME Process Pump MODEL / Series / Product Number ＰＡ３１１３ ＰＡ３２１３...
-
Page 2: Table Of Contents
Contents Safety Instructions ............................... 2 Model Indication and How to Order ......................... 4 Names and Functions of Product Parts ......................5 Piping and Operation ............................6 Working Principle ..............................7 Precautions ................................8 1．Caution on Design .............................. 8 2．Mounting ................................9 3．Piping .................................. -
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. -
Page 4: Limited Warranty And Disclaimer/Compliance Requirements
Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act. -
Page 5: Model Indication And How To Order
Model Indication and How to Order... -
Page 6: Names And Functions Of Product Parts
Names and Functions of Product Parts Bracket Description Functions Suction port Sucks the fluid to be transferred. Connect suction piping. (FLUID IN) Discharge port Discharges the fluid taken in the pump. Connect discharge piping. (FLUID OUT) Pilot air supply port Supplies air of set pressure. -
Page 7: Piping And Operation
Piping and Operation Caution Mounting posture of the pump is set with the mounting bracket facing downward. Maintain the proper tightening torque for fittings and mounting bolts, etc. Looseness can cause problems such as fluid and air leaks, while over tightening can cause damage to threads and parts, etc. Starting and Stopping Refer to circuit example (1）... -
Page 8: Working Principle
Working Principle Control unit 1. When air is supplied to P1 port, it enters drive chamber A. 2. Diaphragm A moves to the left, and at the same time diaphragm B also moves to the left. 3. The fluid in pump chamber A is forced out to the discharge port, and the fluid is sucked into pump chamber B from the suction port. -
Page 9: Precautions
Precautions １．Caution on Design Warning 1. Confirm the specifications. - Give careful consideration to operating conditions such as the application, fluid and environment, and use the product within the operating ranges specified in this catalog. - The product is provided for physical, chemical and industrial equipment. 2. -
Page 10: 2．Mounting
11. Condensation and freezing of the pilot port The air supply port of the air operated type can cool down quickly due to expansion of the supply air, and this may cause condensation on the piping and the condensation may freeze during operation in winter. -
Page 11: 4．Air Supply
４．Air supply Warning 1. Use clean air. Do not use compressed air that includes chemicals, synthetic oils containing organic solvents, salinities or corrosive gases, etc., as it can cause damage or malfunction. 2. Pay attention to avoid freezing when operating the product in low temperatures. The equipment operates while expanding the compressed air. -
Page 12: Maintenance Warning
６．Maintenance Warning 1. Perform maintenance after consulting the operation manual. Obtain the operation manual for the equipment from SMC or our distributor and have sufficient knowledge of the equipment before performing maintenance. Incorrect handling may cause damage or malfunction of the equipment or system. 2. -
Page 13: 7．Lubrication
Operating Diaphragm Model discharge numberof cycles inside pump Method material per cycle A in service life B (wetted part) PA3113 Approx. 50 million Air operated PTFE Approx. 75mL PA3213 0.022L cycles ７．Lubrication Caution 1. The pump can be used without lubrication. -
Page 14: 8．Caution On Handling
８．Caution on Handling Warning 1. Test before using with the actual equipment. Test the pump before using it with the actual equipment. Even if there is no problem in a short-term test, the liquid may penetrate through the fluoropolymer diaphragm causing a malfunction in the pump air circuit. -
Page 15: Applicable Fluids
6. Compatibility is indicated for fluid temperatures specified for the respective products (60℃ or less). Table symbols ○: Can be used. ×: Cannot be used. —: Can be used under certain conditions. Model PA3113 PA3213 Body material ADC12... -
Page 16: Specifications
Specifications Model PA3113 PA3213 Actuation Air operated Main fluid suction Rc, NPT, G, NPTF 3/8" Female thread discharge port Port size Pilot air supply/exhaust Rc, NPT, G, NPTF 1/4" Female thread port Body wetted ADC12 SCS14 areas Material Diaphragm PTFE Check valve PTFE、PFA... -
Page 17: Performance Curve
Performance Curve Flow Rate Characteristics Selection from Flow Rate Characteristic Graph Required specification example: Find the pilot air pressure and pilot air consumption for a discharge rate of 6 L/min. <The transfer fluid is fresh water (viscosity 1 mPa·s, specific gravity 1.0).> Note 1) If the total lifting height is required instead of the discharge pressure, a discharge pressure of 0.1 MPa corresponds to a total lift of 10 m. -
Page 18: Air Consumption
Air Consumption Calculating Air Consumption Find the air consumption for operation with a 4 Hz switching cycle and pilot air pressure of 0.3 MPa from the air consumption graph. Selection procedures: 1. Look up from the 4 Hz switching cycle to find the intersection with SUP = 0.3 MPa. 2. -
Page 19: Viscosity Characteristics
Viscosity Characteristics Selection from Viscosity Characteristic Graph Required specifications example: Find the pilot air pressure and pilot air consumption for a discharge rate of 2.7 L/min, and a viscosity of 100 mPa·s. Selection procedures: 1. First find the ratio of the discharge rate for fresh water when viscosity is 100 mPa·s from the graph below. -
Page 20: Maintenance Parts
Maintenance Parts ● Basically, it is not recommended to disassemble the process pump. However, if this is necessary, be sure to follow the instructions in the maintenance procedure. ● When carrying out this work, wear appropriate protective equipment. Description PA3□13 Diaphragm kit KT-PA3-31 Check valve kit... - Page 21 Revision history 1998-09-24 Initial release 2006-08-21 Rev. A 2008-11-05 Rev. B 2024-10-30 Rev. C Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
