Dual PPS/PFA construction Dual PPS/PFA construction
Withstand pressure and heat cycle performance have been increased.
Port
New PFA
The flow rate has been increased by
even though it is almost the same size as the PA3 series.
Max. flow rate:
Variations
Model
Automatically
operated
Air operated
F e m
a l e t
h r e a
d
Features 1
Check ball
PTFE
Side cover
PPS
Valve seat
New PFA
Large flow rate Large flow rate
20
l
/min (automatically operated)
Mody Diaphragm
material material
PAF3410
New PFA Denatured PTFE
PAF3413
T u b
e e x
t e n s
i o n
Side cover
New PFA
50
Discharge flow
Fitting type
l
rate ( /min)
1 to 20
Female thread
Tube extension
With nut
1 to 15
W i t h
n u t
Diaphragm holding bolt
New PFA
Diaphragm
Denatured
PTFE
%
Option
Foot
Silencer
