SMC Networks Clean Wet PAF3000 Series Instruction Manual page 13

Dimensions: Air Operated Type
PAF3413-
Female thread:
FLUID OUT
Rc, NPT, G 3/8
FLUID IN
Rc, NPT, G 3/8
2-M5
Thread depth 9
Bottom view of body
PAF3413-
Tube extension:
FLUID OUT
1/2 tube extension
FLUID IN
1/2 tube extension
2-M5
Thread depth 9
Bottom view of body
03
N03
F03
4-ø7
P13
P13N
P13F
4-ø7
Process Pump
Air Operated Type
59 74
152
Foot
(Option)
139
59 110
Foot
152
(Option)
139
PAF
Series
AIR SUP (P1)
Rc, NPT, G 1/8
AIR SUP (P2)
Rc, NPT, G 1/8
AIR SUP (P1)
Rc, NPT, G 1/8
AIR SUP (P2)
Rc, NPT, G 1/8
11
