SMC Networks Clean Wet PAF3000 Series Instruction Manual page 4

PAF
Series
How to Order Fittings for Products with Nut (PAF341S Series)
Fittings compatible for the process pump with nut / PAF341S.
For the case when using the process pump with nut, use the fittings which have one nut (including the insert bushing)
removed.
E
Union elbow Union tee
P
Panel mount union Union
Ordering Example
PAF3410S-1S13
Process pump
2
LQ1 E 41
Fitting type
T
Applicable tubing size
Class
4
4
5
5
U
Note) Fittings which are ordered with the process pump at the same time will be shipped in a separate package.
S
A nut (including the insert bushing)
is removed from one location
No. Applicable tubing size (mm) Reducing

1 12 x 10

2
10 x 8

1 19 x 16

2
12 x 10
Note) Select the fitting after confirming the IN / OUT side fitting size and fitting type.
Tubing size
12 x 10
OUT side
LQ1E41-S
Union elbow
LQ1U4B-S
Union
PAF3410S-1S13
IN side
LQ1E41-S
LQ1U4B-S
Tubing size
3/8" x 1/4"
Class No. Applicable tubing size (inch)
4 A 1/2" x 3/8"
4 B
3/8" x 1/4"
5 A 3/4" x 5/8"
5 B
1/2" x 3/8"
 
: Basic size : With reducer
(Union elbow)
(Union)
Reducing




1
1
1
