SMITH SYSTEM NUMBERS DESK 02130 Assembly Instructions Manual page 5

3. To change the leg set to the optional glide version, turn the set screw clockwise until it
stops, remove the leg insert and rotate 180 degrees inserting the glided side of the leg
set into the tube first. Follow step 2 to set the leg height and tighten the insert into place.
Install press in caster as shown.
PART NUMBER: 60290-R
NO. 10X1-1/8" TORX BUTTON HEAD SCREW
NO. 10X1-1/8" TORX BUTTON HEAD SCREW
T25 TORX POWER BIT 2"
Document #: 179722
Assembly Instructions
Replacement Hardware Pack
QTY. 32
QTY. 8 PER LEG ASSEMBLY
QTY. 1
NUMBERS DESK LEG CUSTOM SET SCREW
3/8-16 X .75"
QTY. 8
1/8" ALLEN KEY
QTY. 1
Orientation of tube
shown outside of
assembly for
reference
REVISED: 07/2024
