SMITH SYSTEM 26681 Assembly Instructions Manual

Library carrel adders

Advertisement

Quick Links

Library Carrel Adders
(Adder Unit) See Instruction Sheet 179873 for Starter Unit.
Intermediate
Panel
Right
Panel
Model
Left
26681
Panel
26683
26685
For assistance in assembling product, or to place
an order please contact customer service at
Form# 179874
800-328-1061
02/2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 26681 and is the answer not in the manual?

Questions and answers

Summary of Contents for SMITH SYSTEM 26681

  • Page 1 Library Carrel Adders (Adder Unit) See Instruction Sheet 179873 for Starter Unit. Intermediate Panel Right Panel Model Left 26681 Panel 26683 26685 For assistance in assembling product, or to place an order please contact customer service at Form# 179874 800-328-1061...
  • Page 2 Special Notes: 1. Check that all components are accounted for and undamaged before assembling. 2. Assemble the product in a clean and dry area. 3. For larger units you may need another person to help assemble the product. 4. Clean the product with a mild cleaner and a damp cloth. Tools: You will need a Phillips Head Screwdriver.
  • Page 3 Assembly Instructions Library Carrels (Starter Unit) Urgent: Back panel orientation determines the top height. By rotating 180 degrees you can change the carrel to the desk height or the kiosk height. *Due to size, we recommend that “C” brace on two people should be involved in back panel assembling this product.
  • Page 4 Step 1: Lay the starter unit on the floor; disconnect the connector bolts from the side panel by using the “L” wrench (See Drawing 1A). Next, detach the machine screws from the cross brace; finally remove the 3 wood screws that connect the bracket to the side panel. Left/Right Panel Left/Right...
  • Page 5 Step 3: With help, lay the side panel on the floor while aligning the cross bar with the pilot hole. Attach together by using (2) Machine Screws (See Drawing 3A). Drawing 3A Left/Right Panel Step 4: Lay the adder unit on the floor and align the cross bar with the (2) pilot holes. Attach together by using (2) machine screws.
  • Page 6 Step 5: With help, se the unit upright on its feet and slide the work surface above both brackets until it runs flush against the back panel. Align the predrilled holes underneath the table top with the brackets. Using (6) wood screws, attach the top to the brackets (See Drawing 5A). Drawing 5A For assistance in assembling product, or to place an order please contact customer service at...
