TM/LM-5115 & TM/LM-5116
& TM/LM-5116P
POS Monitor User Manual
SOME IMPORTANT NOTES
FCC NOTES
This system meets industry & government requirements and applicable standards. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions manual, may cause interference to radio communications. It has been tested
and found to comply with limits for a Class A digital device pursuant to subpart B of Part 15 of
FCC Rules, which are designed to provide reasonable protection against interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely
to cause interference in which case the user at his own expense will be required to take whatever
measures to correct the interference.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
CE CLASS A WARNING
This equipment is compliant with Class A of CISPR 32. In a residential environment this
equipment may cause radio interference.
AVERTISSEMENT CE CLASSE A
Cet équipement est conforme à la classe A de CISPR 32. Dans un environnement résidentiel, cet
équipement peut provoquer des interférences radio.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the
authorized technicians. The user should consult his/her dealer for the problem happening.
Warranty voids if the user does not follow the instructions in application of this merchandise. The
manufacturer is by no means responsible for any damage or hazard caused by improper application.
LIMITES DE GARANTIE
La garantie prend fin automatiquement lorsque la machine est ouverte par une personne autre que
les techniciens autorisés. L'utilisateur doit consulter son revendeur pour le problème qui se produit.
La garantie s'annule si l'utilisateur ne suit pas les instructions d'application de cette marchandise.
Le fabricant n'est en aucun cas responsable de tout dommage ou danger causé par une mauvaise
application.
警告
為避免電磁干擾,本產品不應安裝或使用於住宅環境。
TM/LM-5115 & TM/LM-5116 & TM/LM-5116P Ver. A0
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TM-5115 and is the answer not in the manual?

Questions and answers

Summary of Contents for POSIFLEX TM-5115

  • Page 1 TM/LM-5115 & TM/LM-5116 & TM/LM-5116P POS Monitor User Manual SOME IMPORTANT NOTES FCC NOTES This system meets industry & government requirements and applicable standards. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause interference to radio communications.
  • Page 2: Package Contents

    SAFETY INSTRUCTIONS This equipment is not suitable for use in locations where children are likely to be present. CONSIGNES DE SÉ CURITÉ Cet équipement ne convient pas à une utilisation dans des endroits où des enfants sont susceptibles d'être presents. WARNING Power cord shall be connected to a socket-outlet with earthing connection.
  • Page 3 Rear View Side Attachment Cover OSD Keypad Neck Cover Cable Cover Cable Exit Views of TM/LM-5116P Front View LED Indicator P-CAP Touch Panel Side Attachment (Optional) Camera (Optional)
  • Page 4 Rear View OSD Keypad Neck Cover Cable Cover Cable Exit Side Attachment (Optional) OSD Keypad OSD Button EXT Button + Button - Button / Power Button...
  • Page 5 Introduction to the I/O Ports USB (Type B) Port DP Port VGA Port DC-IN Power Jack HDMI Port Positioning your screen for a Perfect Viewing Angle Tilt the screen in the direction shown by the arrow in the figure. Please do not press on the LCD panel while setting up the tilt angle.
  • Page 6 Connecting Power Adapter and I/O Cables Before connecting power adapter and I/O cables to the I/O ports of the POS monitor, please route and arranging the cables. Refer to the following step-by- step instruction of cable routing and arrangement for the details. 1.
  • Page 7 4. Remove the neck cover from the base stand. 5. Tilt the monitor slightly at a little angle in the direction as shown by the arrow, making cables easily pass through the cable passage. Cable Cable Passage Passage TM/LM-5115 & TM/LM-5116 TM/LM-5116P 6.
  • Page 8 7. For TM/LM-5115 & TM/LM-5116: Push and tilt the monitor to the end in the direction as shown by the arrow. And then place the screen face down on a soft mat or PE foam. For TM/LM-5116P: There is no need to place the screen face down. 8.
  • Page 9 TM/LM-5116P 9. Connect the connector of the power adapter to the 12VDC-IN power jack, and connect the display cable and the USB cable (for TM model) to the relevant port. TM/LM-5115 & TM/LM-5116 TM/LM-5116P...
  • Page 10 10. Put the bottom I/O cover back to the monitor. Please note that it should be put in from the outside, and then press the cover downwards. TM/LM-5115 & TM/LM-5116 TM/LM-5116P...
  • Page 11 11. Arrange the cables well and then shield the I/O cable arrangement area on the neck of the base stand with the neck cover. 12. Shield the I/O cable exposure area with the cable cover. CAUTION: On doing insertion or extraction of a cable connector, please always hold the connector head itself instead of pulling the cable wire.
  • Page 12 For TM-5115/5116/5116P Models with P-CAP Touchscreen If your monitors are TM-5115/5116/5116P models, you may configure the display settings from Control Panel in Microsoft Windows to identify the monitor as the secondary touchscreen monitor. Please go through the below steps to complete configuration.
  • Page 13: Specification

    To start up the monitor, please make sure that the monitor is well connected to POS terminals and electricity is supplied to the monitor through POS terminal. Installing Drivers Please visit Posiflex official website to download and install the related drivers. (https://download.posiflex.com/en-global/Download/index/driver/POS- Monitor/TM-5115) Setting up Display Resolution for Your Monitor The below chart defines the list of recommended display settings for TM/LM monitor.
  • Page 14 Power Supply 12V from power adapter Touch Touch type TM-5115: P-CAP TM-5116/5116P: P-CAP LM-5115: N/A LM-5116/5116P: N/A Interface TM-5115: USB TM-5116/5116P: USB LM-5115: N/A LM-5116/5116P: N/A Integrated module Camera Optional, 1MP wide angle camera module Mechanical Mechanical Standalone display with Gen7 base...
  • Page 15 TM/LM-5116...
  • Page 16 TM/LM-5116P...
