POSIFLEX LM-7112 User Manual

LM-7112 / TM-7112
LCD / Touch Monitor
User's Manual
I. FEATURES
Most stable 12.1" LCD monitor with tilt adjust for industrial and
commercial use
Application covers POS, POI (Kiosk), Factory Automation etc.
USB HUB function with 2 ports for optional side mount devices (BC300 or
SD300) or USB KB or mouse
Spill proof and easy maintenance structure allowing easy cleaning
High quality TFT LCD panel with scaling up function for full screen
display
Super VGA interface
Resistive type extra long life touch panel in RS232 or USB interface (for
TM-7112)
Touch functions include left/right button, double click, drag & drop (for
TM-7112)
Touch beep can be pitch adjusted/enabled/disabled by software control (for
TM-7112)
FCC NOTICE
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions manual, may cause interference to radio communications. It has been tested and found to comply with limits
for a Class A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection
against interference when operated in a commercial environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take whatever measures to correct the interference.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the authorized
technicians. The user should consult his/her dealer for the problem happened. Warranty voids if the user does not follow the
instructions in application of this merchandise. The manufacturer is by no means responsible for any damage or hazard caused by
improper application.
ABOUT THIS MANUAL
This manual assists the user to utilize the LCD Monitor LM-7112 and the Touch Monitor TM-7112. These series
provide adjustable robust construction for 12.1" LCD display with maximum resolution of 800 x 600. TM-7112 provides also a
durable touch screen over the LCD panel. Both support a side mount option of SD-300 or BC-300.
The manufacturer of the LM-7112 and TM-7112 series heartily apologizes to the user for reserving the right to
change or to modify this manual without notice due to the rapid and constant progress and improvement on science and technology.
The user may always obtain the most up to date information through any of our web sites: http://www.posiflex.com,
http://www.posiflex.com.tw, http://www.posiflexusa.com.
TRADE MARKS AND SERVICE MARKS
POSIFLEX is a registered trademark of Posiflex Inc..
Other brand and product names are trademarks and registered trademarks and service marks of their respective owners.
P/N: 19660900010
Rev. Original
Copyright Posiflex Inc. 2006
Part 1
