TM/LM-2212E/2312E/2412E/2512E/2612E
LCD Monitor User Manual
Product Features
12.1" rear-mount monitor
High compatibility with various Posiflex terminals
Monitor Model
TM/LM-2212E
TM/LM-2312E
TM/LM-2412E
TM/LM-2512E
TM/LM-2612E
Support of tilt adjustment:
Color choices: Black/Ivory
19630903010 Ver. Original
http://www.posiflex.com
Package Contents
12.1" TM/LM-2X12E LCD Monitor (x 1)
VGA Cable (x 1)
USB type A to B cable for TM-series
monitors (x 1)
Mounting Kits (x 1)
User Manual (x 1)
Posiflex
POS model
XP series models
KS 15"/17" series models
KS-7212E model
XT series models
HS series models
42.5˚〜77.5 ˚
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for POSIFLEX LM-2212E
Summary of Contents for POSIFLEX LM-2212E
- Page 1 (x 1) Mounting Kits (x 1) User Manual (x 1) Product Features 12.1” rear-mount monitor High compatibility with various Posiflex terminals Monitor Model Posiflex POS model TM/LM-2212E XP series models KS 15”/17” series models TM/LM-2312E TM/LM-2412E...
- Page 2 Views of TM/LM-2212E 12.1” LM-2012E LCD Panel 12.1” TM-2012E Resistive Touch Panel Monitor Bracket OSD Buttons Power LED Indicator Front View Rear View Views of TM/LM-2312E/2412E 12.1” LM-2012E LCD Panel 12.1” TM-2012E Resistive Touch Panel Monitor Bracket OSD Buttons Power LED Indicator...
- Page 3 Views of TM/LM-2612E 12.1” LM-2012E LCD Panel 12.1” TM-2012E Resistive Touch Panel OSD Buttons Monitor Bracket Power LED Indicator Front View Rear View View of I/O Interface of OSD Buttons OSD Button EXT Button ＋ Button －Button Power Button View of I/O Interface of LM-2X12E VGA Port DC-IN Power Jack View of I/O Interface of TM-2X12E...
- Page 4 During installation, please ensure the terminal is properly turned off and disconnected from the power sources to avoid potential hazards. Mounting TM/LM-2212E onto XP series terminals XP-3000 will be used to demonstrate installation of TM/LM-2212E in the following example. Position your terminal with its rear facing towards you.
- Page 5 Type-B USB port of your monitor Properly attach Type-A connector of USB cable to the POS terminal. The installation of TM/LM-2212E is completed. Mounting TM/LM-2312E onto 15”/17” KS-series terminals KS-7215 with Gen 8.5 base will be used to demonstrate installation of TM/LM-2312E in the following example.
- Page 6 Insert four #6-32-12L fixing screws into the screw holes and then tighten the screws to secure the mounting bracket. Lay the TM/LM-2312E on a flat surface with the screen facing downward and its I/O ports facing toward you. While holding the monitor steady with one hand, pull the monitor bracket upright.
- Page 7 Pass the cables through the cable exit as shown in the picture. Cable exit Flip the terminal with its rear toward you. Neatly pull the cables out of the cable exit and route it along the cable passage. Push back the neck cover into place. Push back the cable cover.
- Page 8 Mounting TM/LM-2412E onto KS-7212E terminal Position KS-7212E with its rear facing towards you. Take L type mounting bracket out of TM/LM-2412E box package. Align the four screw holes of the mounting bracket with the hole pattern at the back of the terminal. Insert four #6-32-12L fixing screws into the screw holes and then tighten the screws to secure the mounting bracket.
- Page 9 Connect VGA and USB cables to I/O plate of your terminal. Take the VGA cable out of the package. Then, insert one end of VGA cable to the VGA port of your terminal. For TM series users, attach Type-A connector of USB cable to your POS terminal.
- Page 10 The installation of TM/LM-2412E is completed. Mounting TM/LM-2512E onto XT series terminal XT-3615 with Gen 7E base will be used to demonstrate installation of TM/LM-2512E in the following example. The similar cable-routing skill can also be applied to Gen 8E base. Position your terminal with its rear facing toward you.
- Page 11 After positioning your terminal with its screen facing downwards, lift the monitor and then align the four fixing screw holes on its mounting bracket with the hole pattern at the rear of the terminal as shown in the figure. Insert four #6-32-10L screws into the screws holes and then tighten them to secure the mounting bracket.
- Page 12 Push the rails back to the base. If the cable is threaded through the cable passage on the right, by following the sequence number, first slide the shorter rail horizontally and then longer one vertically into place in the direction shown by the arrow to fix your cable into place.
- Page 13 After tucking the extra cable into the bottom I/O compartment, push back the cover to close the compartment. After ensuring TM/LM-2512E is well installed, tilt your monitor up or down to your desired angle. While setting up the tilting adjustment, be careful not to press on the LCD panel.
- Page 14 Lift the monitor up to align the four screw holes of the mounting bracket with the holes in the top I/O interface compartment of your POS as shown in the figure. Insert four #6-32-8L fixing screws into the screw holes and tighten them to secure the mounting bracket.
- Page 15 After ensuring TM/LM-2612E is well installed, tilt your monitor up or down to your desired angle. While setting up the tilting adjustment, be careful not to press on the LCD panel. Identifying your Monitor as Secondary Touchscreen Monitor in Extended Mode Based on the type of your touch panels, you are required to adopt different approaches to set up TM series as the extended monitor when you attempt to extend the desktop across multiple monitors.
-
Page 16: Status Led Indicator
VGA power of the terminals in BIOS settings so that the monitor is able to extract power from the Posiflex terminals. However, if the monitor you are using is not manufactured by Posiflex, it is strongly suggested to deactivate the VGA power of your terminal in preventing your device from being damaged. - Page 17 Powering ON/OFF TM/LM-2X12E Instead of using an external power supply, TM/LM-2X12E mainly depends on Posiflex POS terminals as primary power sources. In such a case, the LCD monitor will be automatically initiated when the terminal is powered up and shut down immediately after you power the POS down. If the monitor does not...
- Page 18 Introducing the Posiflex OSD Menu OSD, as known as On Screen Display, is employed to assist users in adjusting a variety of monitor-related settings depending on personal preference. Through this section, it is expected to familiarize you with the options which...
-
Page 19: Auto Adjustment
OSD Options Posiflex OSD menu contains a set of six OSD options, and each option could be comprised of several sub-options to offer more specific configurations. OSD Menu Options Sub-menu items & Description Backlight Picture Press the “＋” button to increase backlight intensity;... -
Page 20: Specifications
12V from Posiflex terminal VGA port Touch Touch type 5-wire Resistive Interface ※ The product information and specifications are subject to change without prior notice. To get the detailed information on TM/LM- 2212E/2312E/2412E/2512E/2612E, please check this model from Posiflex Global Website (http://www.posiflex.com/en-global/Download/download).
