AMGO Hydraulics OH-15 Installation And Service Manual

Direct-drive two post lift
Hide thumbs Also See for OH-15:
Table of Contents

Advertisement

Quick Links

Download this manual
DIRECT-DRIVE TWO POST LIFT
Cargo Claims
If there is any missing or damaged
product during transportation, the
buyer must notate on the shipping
paperwork or refuse the shipment.
NOTATE ALL DAMAGE OR REFUSE
DAMAGED SHIPMENT!
Model: OH-15
△
DANGER
!
Read the entire contents of this manual before
using this product. Failure to follow instructions
and safety precautions could result in serious
injury or even death. Make sure all other
operators also read this manual. Keep this
manual near the machine so that it can be seen
by all users. By proceeding with installation and
operation, you agree that you are fully
understand the contents of this manual and take
full responsibility for the use of the product.
Original

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OH-15 and is the answer not in the manual?

Questions and answers

Related Manuals for AMGO Hydraulics OH-15

Summary of Contents for AMGO Hydraulics OH-15

  • Page 1 Original DIRECT-DRIVE TWO POST LIFT Model: OH-15 △ DANGER Read the entire contents of this manual before using this product. Failure to follow instructions and safety precautions could result in serious Cargo Claims injury or even death. Make sure all other If there is any missing or damaged operators also read this manual.

  • Page 2: Table Of Contents

    CONTENTS PROFILE ..................1 IMPORTANT SAFETY INSTRUCTIONS ..........3 I. PRODUCT FEATURES AND SPECIFICATIONS ........5 II. INSTALLATION REQUIREMENT ............. 7 III. INSTALLATION STEPS ............... 9 IV. EXPLODED VIEW ..............35 V. TEST RUN ................40 VI. OPERATION INSTRUCTIONS ............. 42 VII. MAINTENANCE SCHEDULE ............43 VIII.

  • Page 3: Profile

    PROFILE The two post lift is a commonly used vehicle repair and maintenance tool that uses a pneumatic hydraulic or electric system that can lift the car up to a certain height so that the vehicle can be placed in a suitable position for inspection and repair. Car lifts can be divided into pneumatic and electric, which have the characteristics of safe and reliable, simple structure and quick installation.
  • Page 4 SAFETY WARNING LABEL Fig.1 Fig. 1...

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS In order to properly maintain your product and ensure operator safety, it is the responsibility of the product owner to read and follow these instructions! 1. Ensure product installation complies with all applicable local regulations and rules, such as Occupational Safety and Health Administration regulations and electrical codes.
  • Page 6 clean, dry, and free of oil. 17. Stay alert. Use common sense to observe what you are doing and stay alert. 18. Check for damaged parts. Check for adjustments to moving parts, damage to parts, or anything that may affect their operation. Do not use the machine if the parts are damaged. 19.

  • Page 7: Product Features And Specifications

    · Single-point safety release with dual safety design . Clear-floor design, provide unobstructed floor use . Overhead safety shut-off device prevents vehicle damage . Standard adjustable heights accommodate varying ceiling heights MODEL OH-15 SPECIFICATION With round rubber pad assy. With saddle adapter assy. Max Lifting Height...
  • Page 8 Arm Swings View Fig. 3 Car in Fig. 4 △ CAUTION When driving the vehicle, stay in the middle between the columns. If you hit any part of the lift, you could damage the car or lift.

  • Page 9: Installation Requirement

    II. INSTALLATION REQUIREMENT TOOLS REQUIRED Rotary Hammer Drill (Φ19) Carpenter’s Chalk   Hammer Screw Sets   Level Bar Tape Measure (7.5m)   English Spanner (12") Pliers   Lock Wrench Wrench set ＃ ＃ ＃ ＃ ＃ ：(10 、13 、14...
  • Page 10 B. Equipment storage and installation requirements. 1．Store the equipment in a dry, non-moldy, non-flammable environment. 2．The lift is only approved for indoor installation and use, and outdoor installation is prohibited. 3．When installing the device, take safety precautions according to the instructions to avoid device damage.

  • Page 11: Installation Steps

    Concrete intensity must be 3,500psi (245kg/cm²) Fig. 7 E. POWER SUPPLY 1. You are required to use a licensed and qualified electrician for the installation process. 2. The power supply require 220V/50Hz, with a cord larger than 12AWG, and must be properly grounded.
  • Page 12 Installation ceiling height requirement: larger than 14.5ft 3000mm 59” (1500mm) 59” (1500mm) Car-in direction Fig. 8 △ CAUTION Installing the lift on a surface with slopes more than 3° could lead to injury or even death. This lift is designed for installation on a flat and level surface only. (Defined as no more than 3/8”...
  • Page 13 Use a carpenter’s chalk line to establish installation layout of baseplate (See Fig. 9) Chalk a line 150 3/4” 3829mm Fig. 9 C. Check the parts before assembly. 1. Whole set of one unit (Packaged lift and hydraulic power unit). (See Fig. 10) Fig.
  • Page 14 3. Take out 2pcs outer column, then move them aside to the installation position. (See Fig. Fig. 12 4. Lift the upper column with a fork lift or hoist, loose the upper bolts of the package bracket, then take out the parts inside the column. (See Fig. 13) Fig.
  • Page 15 6. Move aside the parts and check the parts according to the parts list. (See Fig. & 16) Fig. 16 Parts of 103 Fig. 15 7. Check the parts of the parts bag 1, 2, 3 according to parts bag list (See Fig. 17). Parts bag (1) Parts bag (2) Parts bag (3)
  • Page 16 D. Install parts of outer columns. (See Fig. 18) bolt (M6*20), flat washer, lock washer, hex nut Fig. 18 E. Confirm the installation location and install hydraulic cylinder The two columns are placed upside down on the ground of the installation site, and the installation position of the power-side column is determined according to the condition of the installation site.
  • Page 17 F. Install outer columns The lift is designed with three height settings, choose high setting, medium setting or low setting on your workshop. The high setting is suitable for workshops with a height of over 16.5ft; The medium setting is suitable for workshops with a height between 15.5-16.5ft; The low setting is suitable for workshops with a height between 14.5-15.5ft;...
  • Page 18 G. Install anchor bolts. Position the columns on the installation layout. Check the columns plumbness with level bar, and adjusting with the shims if the columns are not vertical. Do not tighten the anchor bolts yet. (See Fig.23) Width between columns:123 1/2”...
  • Page 19 H. Install overhead top beam 1. Hang the hook of top beam(Left) on the outer column, and then align the holes and install the bolts. (See Fig. 24) Hook on the outer columns Hex bolt(M12*35) with dual flat washer, lock washer, hex nut Install the bolts but not tighten Fig.
  • Page 20 2. Hang the hook of top beam (Right) on the other outer column, and then bolted to top beam (Left). (See Fig. 25) Hex bolt(M12*35) with dual flat washer, lock washer, hex nut Tighten the anchor bolts with ratchet spanner with socket Torque of tighten the anchor bolts is 150 N.m(1328lbf.in) Fig.25...
  • Page 21 I. Install control bar for limit switch (See Fig. 26) 1. Fix the the control bar on the top beam first. Off-side Power-side Fix the control bar support bracket with Hex bolt (M10*20), nut, lock washer, flat washer Control bar support bracket Hex bolt (M8*16mm) Control bar...
  • Page 22 J. Install safety device (See Fig. 28 & 29). Fig. 28 Power-side safety device 13 14 Fig. 29 Offside safety device △ DANGER Make sure the safety device are properly installed before using the lift.
  • Page 23 K. Install sync cables Raise both sides of carriages and lock them to the same level. 1. Sync cable connection of high setting installation 1.1 Remove the carriages plastic cover, sync cable across from the bottom of the carriages and pull it out from the hole of carriage, then tighten two cable nuts. (See Fig. 30) Tighten Cable connecting direction...
  • Page 24 1.2 Connecting sync cable for high setting. (See Fig. 31) High Setting: Align lower holes of outer columns with inner columns. Cable 2 Cable 1 Cable 1 Fig. 31...
  • Page 25 2. Sync cable connection of medium setting installation. (See Fig.32) Medium Setting: Align middle holes of outer columns with inner columns. Cable 2 Cable 1 Cable 2 Cable 1 Fig. 32...
  • Page 26 3. Sync cable connection of low setting installation. (See Fig. 33) Attention: the sync cable should be along inside of column. Setting: Align upper holes of outer columns with inner columns Cable 2 Cable 1 Cable 2 Fig. 33...
  • Page 27 L. Install power unit (See Fig. 34) Fig.34...
  • Page 28 Install oil hose of high, medium and low setting. 1. Oil hose installation of high setting.(Fig.35) hose wire across the Oil hose across the wire support plate clamp on top beam Connect power unit fitting and oil hose Connect oil hose and cylinder Fig.35...
  • Page 29 2. Oil hose installation of medium setting.(Fig.36) Fig.36 3. Oil hose installation of low setting.(Fig.37) Fig.37...
  • Page 30 N. Install wire protective cover and sync cable limit plate.(See Fig.38) (No.:86 wire protective cover: Install 1pc for each column in low setting; install 2pcs for each column in medium setting; install 3pcs for each column in high setting) Socket bolt(M6*16) with flat washer, lock washer After installation of the...
  • Page 31 O. Install lock release cable Install lock release cable. Start from off-side safety device, then pass it through the top beam, finally connect to power-side safety device. (See Fig. 39) Safety cable across outside of the small Safety cable pulley bracket goes through small pulley bracket...
  • Page 32 P. Install safety device cover (See Fig. 40) Round head bolt(M6*8), flat washer Fig.40...
  • Page 33 Q. Install lifting arms 1. Install lifting arms according to the figure, then install spring on the arm pin, last install bar.(See Fig.41) guard Install with hex bolt(M8*16), lock washer, flat washer Use round rubber pad saddle adapter accordingly Fig.41 2.
  • Page 34 △ WARNING Each arm restraint assembly must be inspected and adjusted before you use the Lift each and every time. Do not operate the Lift if any of the four arm restraint systems are not functioning properly. Replace any broken components or components with broken teeth with authorized replacement parts only.
  • Page 35 Motor wiring diagram of single phase power unit Circuit diagram Limit switch Control button Fig. 46 Power source wires Remove this jumper wire Limit switch wire Fig. 47 Fig. 48 △ DANGER All wiring must be performed by a licensed, certified Electrician. Do not perform any maintenance or installation of the lift without first ensuring that the main power supply has been disconnected from the lift and that it cannot be re-energized until all procedures have been completed.

  • Page 36: Exploded View

    IV. EXPLODED VIEW Model OH-15 Fig. 49...
  • Page 37 PARTS LIST FOR MODEL OH-15 Item Part# Description 11217458-02 Power-side column 071102 Power unit Hex bolt M8*25 (Include flat washer, lock washer, 1002735003 hex nut) 11217405 Power-side safety device cover 1002735004 Round head bolt M6*8 (Include flat washer) 10217005 Plastic ball M10 11217006 Safety Lock handle 5/8"×5 5/8"...
  • Page 38 Item Part# Description 11217024 Oil hose supporter 11217470-02 Outer column L=92 3/4" 11217068 Column Reinforce Plate 11217406 Offside safety device cover 10217008 Safety Spring φ2.5*145° 11217031 Offside Cam Lock 10217032 Cable connecting pin 11217033 Nylok Nut 11217029 Pulley bracket 1002735011 Hex bolt M6*15 (Include flat washer) 11217459-02 Offside column...
  • Page 39 Item Part# Description 11217037 Bottom pin 31/32"×1 25/32" 11217036-01 Bottom pulley 5 3/4"×23/32" 10217114A Rubber pad assy. 1021103 Saddle adapter assy. 100273012 Hex bolt M8*16/(Include flat washer, lock washer) 11206154 Rear toe guard 10206156 Tool tray 11203778-01 Wire Protective cover L=61 13/32" 10206079 Cup Head Bolt M6*40 1102781001...
  • Page 40 1. Lifting Arm Exploded View (10217052D) Fig. 50 Item Part# Description Qty. Socket bolt (M12*48), flat washer, lock 1102205004 washer 1102163001 Moon gear 11217122 Outer arm 10201149 Flat head screw M8*12 11217123A Inner arm 2. Cylinders Exploded View (10217056B) Fig. 51...
  • Page 41 Item Part# Description Qty. Note 10209069 O-Ring 10209070 Bleeding Plug 10201029 Support Ring 10201030 Y-Ring 10201031 O-Ring 11217074A Piston 10217075 O-Ring 11217089 Piston rod 11217077 Piston rod fitting 10217078 Dust ring 11217079 Head cap 10217080 O-Ring 11217091 Bore weldment 3. Illustration of hydraulic valve for hydraulic power unit (See Fig.

  • Page 42: Test Run

    V. TEST RUN 1. Adjustment of sync cable (See Fig. 53) Use an open spanner to clamp the cable joint, and use a ratchet wrench to tighten the cable nut until the two sync cables are adjusted to a certain tension force and are consistent.
  • Page 43 4. Adjust the lowering speed If necessary, you can adjust the lower speed of the lift by turning the throttle valve clockwise to decrease it, or counterclockwise to increase the lower speed. Throttle Valve Throttle Valve Counterclockwise to increase lowering speed Clockwise to decrease the lowering speed Fig.

  • Page 44: Operation Instructions

    VI. OPERATION INSTRUCTIONS Please read the safety tips carefully before operating the lift To lift vehicle 1. Keep operation site clean; 2. Lower the lifting arm to the shortest position; 3. Retract the lifting arm to the shortest position; 4. Open lifting arms out to the sides; 5.

  • Page 45: Maintenance Schedule

    VII. MAINTENANCE SCHEDULE Monthly: 1. Tighten the anchor bolts with to 150 Nm torque force; 2. Check all fittings, bolts and pins to ensure proper connections; 3. Lubricate cable and slider with lubricant; 4. Make a visual inspection of all oil hoses/lines for possible wear or leakage; 5.

  • Page 46: Trouble Shooting

    VIII. TROUBLE SHOOTING TROUBLE CAUSE REMEDY 1. Button does not work 1. Replace button 2. Wiring connections are not in good 2.Repair all wiring connections condition Motor does not 3. Motor burned out 3. Repair or replace motor 4. Height limit switch is damaged 4.Replace the limit switch 5.

  • Page 47: Car Lift Safety Tips

    IX. CAR LIFT SAFETY TIPS Put these safety tips in a place where you can always alert the operator. Please reference to the lift manufacturer’s manual for specific information about the lift. 1. Check the lift daily. If the machine breaks down or has damaged parts, do not operate, and use the parts of original equipment to repair.
  • Page 48 AMGO HYDRAULIC CORPORATION Address: SC Division: 1931 Joe Rogers Jr Blvd, Manning, SC 29102, USA TX Division: 4310 Adler Dr., Suite #200, Dallas, TX 75211, USA Tel: (803) 505-6410 Fax: (803) 505-6410 Manual Part No.: 72228508 Revision Date: 2023/12...
