AMGO Hydraulics OH-10 Installation And Service Manual

Direct-drived two post lift
Hide thumbs Also See for OH-10:
Table of Contents

Advertisement

Quick Links

Download this manual
DIRECT-DRIVED TWO POST LIFT
Cargo Claims
If there is any missing or damaged
product during transportation, the
buyer must not ate on the shipping
paperwork or refuse the shipment.
NOTATE ALL DAMAGE OR REFUSE
DAMAGED SHIPMENT!
Address:
SC Division: 1931 Joe Rogers Jr Blvd, Manning, SC 2912, USA
TX Division: 4310 Adler Dr., Suite #200, Dallas TX 75211, USA
Model: OH-10
△
DANGER
!
Read the entire contents of this manual before
using this product. Failure to follow instructions
and safety precautions could result in serious
injury or even death. Make sure all other
operators also read this manual. Keep this
manual near the machine so that it can be seen
by all users. By proceeding with installation and
operation, you agree that you are fully
understand the contents of this manual and take
full responsibility for the use of the product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OH-10 and is the answer not in the manual?

Questions and answers

Related Manuals for AMGO Hydraulics OH-10

Summary of Contents for AMGO Hydraulics OH-10

  • Page 1 DIRECT-DRIVED TWO POST LIFT Model: OH-10 △ DANGER Read the entire contents of this manual before using this product. Failure to follow instructions and safety precautions could result in serious Cargo Claims injury or even death. Make sure all other operators also read this manual.

  • Page 2: Table Of Contents

    CONTENTS PROFILE ..................1 OWNER/EMPLOYER RESPONSIBILITIES ..........2 IMPORTANT SAFETY INSTRUCTIONS ..........3 SAFETY WARNING LABEL ..............5 I. PRODUCT FEATURES AND SPECIFICATIONS ........6 II. INSTALLATION REQUIREMENT ............. 9 III. INSTALLATION STEPS ..............11 IV. EXPLOSIVE VIEW ..............33 V. TEST RUN ................39 VI.

  • Page 3: Profile

    PROFILE The two post lift is a commonly used vehicle repair and maintenance tool that uses a pneumatic hydraulic or electric system that can lift the car up to a certain height so that the vehicle can be placed in a suitable position for inspection and repair. Car lifts can be divided into pneumatic and electric.

  • Page 4: Owner/Employer Responsibilities

    damage resulting in breach of or delay in the execution of the warranty. The manufacturer reserves the right to design and improve the product and has no obligation to make notice of the changes in advance. The product warranty based on the above clause is based on the model number and serial number of the equipment.

  • Page 5: Important Safety Instructions

    recommended by the lift manufacturer’s instructions or ANSI/ALI ALOIM-2020 or a more current edition, American National Standard for Automotive Lifts - Safety Requirements for Operation, Inspection and Maintenance. 5．The Owner/Employer shall display the lift manufacturer’s operating instructions; ALI/SM22-1 or a more current edition, ALI Lifting it Right safety manual;...
  • Page 6 3. Do not operate the lift until you are sure all parts are in place and operating correctly. 4. Keep your hands and feet away from the machine. Keep hands and feet away from any moving parts. Keep your feet away from the lift as it descends to avoid pressing on pointed objects.

  • Page 7: Safety Warning Label

    For additional safety instructions regarding lifting, lift types, warning labels, preparing to lift, vehicle spotting, vehicle lifting, maintaining load stability, emergency procedures, vehicle lowering, lift limitations, lift maintenance, good shop practices, installation, operator training and owner/employer responsibilities, please refer to “Lifting It Right” (ALI/SM) and “Safety Tips”...

  • Page 8: Product Features And Specifications

    Fig. 2 I. PRODUCT FEATURES AND SPECIFICATIONS CLEAR-FLOOR DIRECT-DRIVE TWO POST LIFT FEATURES Model OH-10 · Direct-drive technology minimizes the lift wear on parts and decreases failure rate. · Self- lubricating UHMW Polyethylene sliders and bronze bushings offer smooth operation..
  • Page 9 Arm Swings View Fig.3 Fig.4 Car in △ CAUTION When driving the vehicle, stay in the middle between the columns. If you hit any part of the lift, you could damage the car or lift.
  • Page 10 ATTENTION Please identify the recommended location and shape of vehicle lift points refer “Vehicle lift points for service garage lifting SAE J2184” to determine the center of gravity position of the vehicle. After the car passes, spread the arm to support the support point. Before lifting the vehicle, make sure it is neither front nor rear heavy.

  • Page 11: Installation Requirement

    II. INSTALLATION REQUIREMENT A. TOOLS REQUIRED  Rotary Hammer Drill (Φ19) Carpenter’s ink marker   Hammer Screw Sets   Level Bar (4”) Tape Measure (295-1/4")   English Spanner (12") Pliers   Ratchet Spanner with Socket (28 Lock Wrench ...
  • Page 12 B. Equipment storage and installation requirements. 1. Store the equipment in a dry, non-moldy, non-flammable environment. 2. The lift is generally approved for indoor installation and use. Outdoor installation is prohibited. 3. When installing the machine, take safety precautions according to the instructions to avoid device damage.

  • Page 13: Installation Steps

    III. INSTALLATION STEPS A. Selecting the Location of Installation for OH-10 should consider: 1．Architectural plans. Consult the architectural plans for your desired installation location. Make sure there are no contradictions between what you want to do and what the plans show.
  • Page 14 6．Floor. The lift should only be installed on a flat, level concrete surface and not on asphalt or any other type of flooring. It is important to ensure that surface not more than 3° slope before installation. Workshop ceiling height larger than 151”...
  • Page 15 B. Use a carpenter’s ink marker line to establish installation layout of base-plate (See Fig.10) Click a line 135” Fig.10 C. Check the parts before assembly. 1. Packaged lift and power unit ( See Fig. 11). Fig. 11 2. Move aside the lift with forklift or crane, and open the package, take off the lifting arms and parts box to nearby installation site, check the parts according to the shipment parts list and inner package list (See Fig.12).
  • Page 16 4. Move aside the parts and check the parts according to the shipment parts list. (See Fig.13 & 14). Parts in the parts box (89) Fig. 14 Parts in the shipment parts list Fig. 13 5. Open the parts bag 1 and 2; check the parts according to the list (See Fig.
  • Page 17 D. Install parts of extension columns (See Fig. 16). (Assemble with M6*15 Fig. 16 hex bolt, lock washer, flat washer, nut) E. Position columns Place both columns laying down in installation site. Position the power-side column according to the actual installation site. Usually, it is suggested to install power-side column on the right-front side of vehicle entry direction which vehicles.
  • Page 18 2. Low Setting, connecting the upper holes of outer columns with inner columns (See Fig. 18). Assemble with M10*30 Hex bolt, lock washer, dual flat washers and nut Low setting Fig.18 F. After fully assembling columns, install the anchor bolts. Check the Columns plumpness with level bar, and adjusting with the shims if the columns are not vertical.
  • Page 19 △ CAUTION Concrete and anchor bolts must comply with above specifications. Install lifts only on concrete surfaces. If you are in asphalt or either any other surface on which the lift is mounted, or the concrete or anchor bolts do not meet these specifications, it may result in product damage, vehicle damage, personal injury, or even loss of life.
  • Page 20 After install the other top beam on off side outer column, bolt both top beams and bolts. (See Fig. 21) tighten all the bolts. Finally tighten the anchor Assemble with M10*30 Hex bolt, lock washer, dual flat washers, nut Power side column Tighten the anchor bolts with socket wrench.
  • Page 21 H. Install the limit switch control bar and limit switch (See Fig. 22). 1. Fix the limit switch control bar on to the top beam bracket. Power-side Off-side Loosen the bolts slightly here, adjust the distance between two control bar support bracket, tighten the control bar until it can swing flexibly Limit switch...
  • Page 22 I. Install safety device (See Fig. 23). Install safety device handle on to the power-side safety device Fig.23 △ DANGER Make sure the safety device is properly installed before using the lift.
  • Page 23 Install cables Lift the carriages up and lock them be locked at the same level. 1. Cable connection of low setting installation. (See Fig. 24). Setting installation holes Cable2 Cable1 Hex nut (M16) Cable2 Fig. 24...
  • Page 24 2. Cable connection of high setting installation. 2.1. Run the cable across from the bottom of the carriage and pull it out from the hole of carriage, then tighten two cable nuts. (See Fig. 25). High Setting installation holes Screw the two cable nuts Cable Connection direction Cable connection direction Fig.
  • Page 25 2.2 Cable connection for high setting (See Fig. 26). Cable 2 Cable 1 Hex nut (M16) Cable 2 Fig. 26...
  • Page 26 K. Install power unit (See Fig. 27) Fig.27...
  • Page 27 L. Install oil hose. 1. Connect 3 oil hoses as shown. (See Fig.28) Fig.28...
  • Page 28 2. Follow these steps to connect the oil hose with power unit. Oil outlet port(Left) Oil outlet port(Right) Socket iron plug Assemble 90° fitting to connect Remove the socket iron plug from the power unit with oil hose. the right oil outlet port. Red plastic plug C.
  • Page 29 M. Install protective cover and cable limit plate. (Fig.30) Install with M6*16 socket bolt, lock washer and flat washer. Cable limit plate 1. Screw M6*40 round head bolt slightly; 2. Install protective cover, tighten the round head bolts. Only for high setting Install protective cover to secure oi hose.
  • Page 30 N. Install safety cable (See Fig. 31) (Install safety cable. Start from off-side safety device, then pass it through the top beam, finally connect to power-side safety device.) Lock release cable across outside of wire clamp Safety cable across pulley bracket Wire of limit switch Oil hose...
  • Page 31 O. Install safety device cover (See Fig.32) Round head bolt M6*8 with flat Fig.32 washer...
  • Page 32 P. Install lifting arms, then install spring on the arm pin. Last install guard bar. The process of engaging arm lock and moon gear: Lowing the carriages down to the lowest position, then use the 8 socket head wrench to loosen the socket bolt (See Fig.
  • Page 33 Q. Tighten all the hydraulic fittings, fill the reservoir with hydraulic oil. Note: In consideration of hydraulic power unit’s durability and keep the equipment running in the perfect condition, please use hydraulic oil 46#. R. Install electrical system Connect the power source according to the nameplate of the motor. Note:1.
  • Page 34 2. Connecting the limit switch wire: Remove the short wire that connects # 4 and # A2 as shown in Fig.39. Then according to the wire number of the limit switch, connect them respectively to terminal 4# of control button and A2# of AC contactor. Power source wires Remove this short wire...

  • Page 35: Explosive View

    IV. EXPLOSIVE VIEW Fig.
  • Page 36 PARTS LIST Item Part No. Description QTY. 10206009 Small pulley(White) 11217379 Safety Cable Bracket 1002215005 Hex bolt(M10*35), Lock washer, nut 1061K074 Protective ring 11217024 Oil hose retainer 1002215011 Hex bolt(M6*15), lock washer, flat washer, nut 11279024 Off-side inner column 1002215006 Hex bolt(M10*30),lock washer,dual flat washers,nut 11206196-01 Top beam B...
  • Page 37 Item Part No. Description QTY. Nylok Nut 11217033 11217406 Off-side safety cover 1002215012 Hex bolt(M6*15), flat washer 11217029 Safety Pulley Bracket 10209015 Slider 11217046 Arm lock bar(Right) Cylinder φ50*1727(L=68”) 1002216000 10209111 Cylinder protective ring 11279004 Carriage 10209016 Plastic cover 10209018 Protective rubber block Flat Head Screw M6*16 10209019...
  • Page 38 Item Part No. Description QTY. Cable assy. φ9.52*10048mm(L=395-19/32") 10206064A 10211016 T fitting Oil hose assy. 1/4”*5350mm(L=210-5/8") 10206130-01 Straight fitting 10209064 11233009 Straight fitting 10206062 Straight fitting Oil hose assy. 1/4”*4470mm(L=175-31/32") 10206132-01 10209060 Power unit 90° fitting 1102075001 Cable limit plate 1002215010 Socket bolt(M6*16), lock washer, flat washer Safety cable φ2.5*7750mm(L=305- 1/8")
  • Page 39 4.2 Front left arm assy. (1102214005C) explosive view Fig.43 Item Part No. Description QTY. 10206048 Socket bolts M10*30 10209039 Lock Washer φ10 10209022 Flat Washer φ10 11206049 Moon gear 1102214005A Outer arm-Front left 1102214009A Middle arm - Front 10201149 Round head bolt M8*12 1102214010A Inner arm - Front 4.3 Front right arm assy.
  • Page 40 4.4 Cylinder (1002216000) explosive view Fig. 45 Item Part No. Description QTY. 30-1 10209069 O-ring 30-2 10209070 Bleeding Plug 30-3 1002576003 Support Ring 30-4 11720114 Pressure Compensated Flow Restrictor (0.7 Spring) 30-5 10209071 Wear ring 30-6 10209072 Y-ring OSI 30-7 10209073 O-Ring 30-8...

  • Page 41: Test Run

    4.5 Illustration of hydraulic valve for hydraulic power unit Release Oil inlet port Relief valve valve Oil outlet port Throttle Release valve handle Check valve Fig.46 V. TEST RUN 1. Adjustment of synchronous cable (See Fig. 47) Use an open spanner to clamp the cable joint, and use a ratchet wrench to tighten the cable nut until the two synchronous cables are adjusted to a certain tension force and Adjust...
  • Page 42 4. Adjust the lower speed If necessary, you can adjust the lower speed of the lift by turning the throttle valve clockwise to decrease it, or counterclockwise to increase the lower speed. Throttle Valve Throttle Valve Clockwise to decrease the down speed Counterclockwise to increase the down speed Fig.

  • Page 43: Operation Instructions

    VI. OPERATION INSTRUCTIONS Make sure read thoroughly the Important safety instructions before operating the lift. The failure of reading such instructions could lead to serious injury or even death. To lift vehicle 1. Keep operation site clean; 2. Lower the lifting arm to its lowest position; 3.
  • Page 44 Safety lock working status Safety lock being open Fig.52 Fig.53 To lower vehicle 1. Clear obstructions around and under the lift and be certain no people are around the lift; 2. Push UP button to raise the vehicle slightly, and then unlock the safety device, lower vehicle by pushing release handle on the power unit.
  • Page 45 TYPICAL LIFTING POINTS ATTENION: Some vehicles may have the manufacturer’s Service Garage Lift Point locations identified by triangle shape marks on its undercarriage (reference SAE J2184). There may also be a label located on the right front door lock face showing specific vehicle lift points.

  • Page 46: Maintenance Schedule

    VII. MAINTENANCE SCHEDULE Before starting the maintenance of the lift, the trained lift service personnel should provide the warning or remark according to ANSI Z244.1-1982 (R1993) , Energy Cut / Warning Marking Safety Requirements. Cable inspection and maintenance 1. The cables should be replaced every three to five years or when there are obvious signs of damage.
  • Page 47 ATTENTION: All anchor bolts should take full torque. If any of the bolts does not function for any reason, DO NOT use the lift until the bolt has been replaced. △ WARNING Always use parts provided by the AMGO lift manufacturer or authorized by the manufacturer, if you use non-standard parts obtained from other sources resulting in damage to the lift is not covered by the warranty, and the use of non-standard parts may endanger the safety of the installer/operator.

  • Page 48: Trouble Shooting

    △ DANGER Ensure that the lift is completely disconnected from the power supply before performing any maintenance on the lift. If your lift external electrical devices have locks/shutdowns, make sure to implement them before performing any maintenance. If you come into contact with high voltage/current, it may result in injury or even death.

  • Page 49: Car Lift Safety Tips

    1. Oil line is jammed 1. Clean the oil line 2. Motor running on low voltage 2. Check electrical system Lift raises 3. Oil mixed with air 3. Fill tank slowly 4. Gear pump leaks 4. Replace pump 5. Overload lifting 5.

  • Page 50: Lift Disposal

    8. Note, removing(or installing) parts from a car can cause a sudden shift of gravity that is unstable for the raised car. Reference to the car manufacturer’s service manual as a recommended procedure when removing parts from the car. 9. Before lower the lift , make sure that the tool tray, tool rack, etc.are removed from under the car.
  • Page 51 72128702 2024/04...
