TYGER LanderX
BEFORE INSTALLATION
READ INSTRUCTIONS CAREFULLY BEFORE STARTING
INSTALLATION. REMOVE CONTENTS FROM BOX AND
VERIFY ALL PARTS ARE PRESENT. FAILURE TO IDENTIFY
DAMAGE BEFORE INSTALLATION COULD LEAD TO A
REJECTION OF ANY CLAIM. IF MISSING PARTS OR ANY
DAMAGE FOUND, PLEASE TAKE A PICTURE FOR THE
CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT:
WWW.TYGERAUTO.COM/CONTACT
Driver/Left TYGER LanderX
x1
Passenger/Right TYGER LanderX
x1
Driver/Left Mounting Brackets
x4
Passenger/Right Mounting Brackets
x4
Customer Support: www.tygerauto.com/contact
TORQUE VALUES
8mm x 30mm Hex Bolts
x16
8mm x 25mm Combo Bolts
x16
8mm Lock Washers
x16
8mm x 24mm OD x 2mm Flat Washers
x16
(4) Passenger/Right
Mounting Brackets
Passenger/Right TYGER LanderX
Fastener Size
Class 8.8 Torque (ft-lbs)
6mm
6-7
8mm
15-16
10mm
31-32
12mm
54-55
14mm
87-88
(4) Driver/Left
Mounting Brackets
1/3
TG-LX3C82318
Class 10.9 Torque (ft-lbs)
6-7
22-23
44-45
78-79
125-126
Front
V230511
