RISER
®
BEFORE INSTALLATION
READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. REMOVE
CONTENTS FROM BOX AND VERIFY ALL PARTS ARE PRESENT. FAILURE TO
IDENTIFY DAMAGE BEFORE INSTALLATION COULD LEAD TO A REJECTION OF
ANY CLAIM. IF MISSING PARTS OR ANY DAMAGE FOUND, PLEASE TAKE A
PICTURE FOR THE CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT:
WWW.TYGERAUTO.COM/CONTACT
TORQUE VALUES
Fastener Size
Class 8.8 Torque (ft-lbs)
6mm
8mm
10mm
12mm
14mm
TG-RS6C60248
Class 10.9 Torque (ft-lbs)
6-7
15-16
31-32
54-55
87-88
125-126
(8) Mounting Brackets
Passenger/Right 6inch Tyger Sidebar
Customer Support: www.TygerAuto.com/Contact
Parts List
x1
x1
x8
x16
6-7
x16
22-23
44-45
x16
78-79
x16
1/3
Driver/Left 6inch Tyger Sidebar
Passenger/Right 6inch Tyger Sidebar
Mounting Brackets
8mm x 30mm Hex Bolts
8mm x 25mm Combo Boltss
8mm Lock Washers
8mm x 24mm OD x 2mm Flat Washers
Front
V210922
Advertisement
Related Manuals for Tyger RISER TG-RS6C60248
Summary of Contents for Tyger RISER TG-RS6C60248
- Page 1 CONTENTS FROM BOX AND VERIFY ALL PARTS ARE PRESENT. FAILURE TO IDENTIFY DAMAGE BEFORE INSTALLATION COULD LEAD TO A REJECTION OF Driver/Left 6inch Tyger Sidebar ANY CLAIM. IF MISSING PARTS OR ANY DAMAGE FOUND, PLEASE TAKE A PICTURE FOR THE CLAIM PURPOSE. TO FILE YOUR CLAIM, PLEASE VISIT: WWW.TYGERAUTO.COM/CONTACT...
- Page 2 PROCEDURE: REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. (2) 8mm Hex Bolts ASSISTANCE IS RECOMMENDED. (2) 8mm Lock Washers (2) 8mm Flat Washers STEP 1 Start the installation under the Passenger/Right side of the vehicle.
- Page 3 Board to the Mounting Brackets STEP 5 Front (Fig 6) Passenger/Right 3rd mounting location Level and adjust the Tyger Sidebar and fully tighten all hardware. STEP 6 Repeat STEPs 1-5 to attach the Driver/Left 6inch Tyger Sidebar. Front STEP 7...
