Cypress Semiconductor CY7C1410AV18 Specification Sheet

Features
■ Separate independent read and write data ports
❐
Supports concurrent transactions
■ 250 MHz clock for high bandwidth
■
2-word burst on all accesses
■ Double Data Rate (DDR) interfaces on both read and write ports
(data transferred at 500 MHz) at 250 MHz
■ Two input clocks (K and K) for precise DDR timing
❐
SRAM uses rising edges only
■ Two input clocks for output data (C and C) to minimize clock
skew and flight time mismatches
■ Echo clocks (CQ and CQ) simplify data capture in high-speed
systems
■ Single multiplexed address input bus latches address inputs
for both read and write ports
■ Separate port selects for depth expansion
■
Synchronous internally self-timed writes
■
Available in x8, x9, x18, and x36 configurations
■ Full data coherency, providing most current data
■ Core V = 1.8V (±0.1V); IO V
DD
■ Available in 165-Ball FBGA package (15 x 17 x 1.4 mm)
■ Offered in both Pb-free and non Pb-free packages
■
Variable drive HSTL output buffers
■
JTAG 1149.1 compatible test access port
■ Delay Lock Loop (DLL) for accurate data placement
Configurations
CY7C1410AV18 – 4M x 8
CY7C1425AV18 – 4M x 9
CY7C1412AV18 – 2M x 18
CY7C1414AV18 – 1M x 36
Selection Guide
Description
Maximum Operating Frequency
Maximum Operating Current
Cypress Semiconductor Corporation
Document #: 38-05615 Rev. *E
= 1.4V to V
DDQ DD
250 MHz
250
x8 800
x9 800
x18 850
x36 1000
• 198 Champion Court
CY7C1410AV18, CY7C1425AV18
CY7C1412AV18, CY7C1414AV18
36-Mbit QDR™-II SRAM 2-Word

Functional Description

The CY7C1410AV18, CY7C1425AV18, CY7C1412AV18, and
CY7C1414AV18 are 1.8V Synchronous Pipelined SRAMs,
equipped with QDR-II architecture. QDR-II architecture consists
of two separate ports: the read port and the write port to access
the memory array. The read port has data outputs to support read
operations and the write port has data inputs to support write
operations. QDR-II architecture has separate data inputs and
data outputs to completely eliminate the need to "turn-around"
the data bus required with common IO devices. Access to each
port is accomplished through a common address bus. The read
address is latched on the rising edge of the K clock and the write
address is latched on the rising edge of the K clock. Accesses to
the QDR-II read and write ports are completely independent of
one another. To maximize data throughput, both read and write
ports are provided with DDR interfaces. Each address location
is associated with two 8-bit words (CY7C1410AV18), 9-bit words
(CY7C1425AV18), 18-bit words (CY7C1412AV18), or 36-bit
words (CY7C1414AV18) that burst sequentially into or out of the
device. Because data can be transferred into and out of the
device on every rising edge of both input clocks (K and K and C
and C), memory bandwidth is maximized while simplifying
system design by eliminating bus "turn-arounds."
Depth expansion is accomplished with port selects, which
enables each port to operate independently.
All synchronous inputs pass through input registers controlled by
the K or K input clocks. All data outputs pass through output
registers controlled by the C or C (or K or K in a single clock
domain) input clocks. Writes are conducted with on-chip
synchronous self-timed write circuitry.
200 MHz 167 MHz
200
700
700
725
850
,
• San Jose CA 95134-1709
Burst Architecture
Unit
167 MHz
620 mA
620
650
740
• 408-943-2600
Revised June 13, 2008
