Errata Document for TrueTouch
This document describes the errata for the TrueTouch
trigger conditions, scope of impact, available workarounds, and silicon revision applicability. Compare this document
to the device's data sheet for a complete functional description.
Contact your local Cypress Sales Representative if you have questions.

CY8CTMG200 and CY8CTST200 Errata Summary

The following Errata items apply to the CY8CTMG200 and CY8CTST200 datasheets 001-47603 and 001-47602.

1. Latch-up susceptibility when maximum I/O sink current exceeded

PROBLEM DEFINITION
n
P1[3], P1[6], and P1[7] pins are susceptible to latch-up when the I/O sink current exceeds 25 mA per pin on
these pins.
PARAMETERS AFFECTED
n
LU – Latch-up Current. Per JESD78A, the maximum allowable latch-up current per pin is 100 mA. Cypress
internal specification is 200 mA latch-up current limit.
TRIGGER CONDITION(S)
n
Latch-up occurs when both of the following two conditions are met:
A. The offending I/O is externally connected to a voltage higher than the I/O high state, causing a current to
flow into the pin that exceeds 25 mA
B. A Port1 I/O adjacent (P1[1], P1[4] and P1[5] respectively) to the offending I/O is connected to a voltage
lower than the I/O low state, causing a signal that drops below Vss (signal undershoot), causing a current
greater than 200 mA to flow out of the pin
Scope Of Impact
n
The trigger conditions outlined above exceed the maximum ratings specified in the CY8CTMG200 and
CY8CTST200 datasheets 001-47603 and 001-47602.
Workaround
n
Add a series resistor >300
FIX STATUS
n
This issue will be corrected in the next new silicon revision.
The following Errata item applies only to the CY8CTMG200-48LTXI, CY8CTST200-48LTXI, and CY8CTMG200-
00LTXI, parts on the 001-47603 and 001-47602 Datasheets.
2. Does not meet USB 2.0 specification for D+ and D- rise/fall matching when supply voltage is under 3.3V
PROBLEM DEFINITION
n
Rising to falling rate matching of the USB D+ and D- lines has a corner case at lower supply voltages, such
as those under 3.3V.
PARAMETERS AFFECTED
n
Rising to falling rate matching of the USB data lines.
TRIGGER CONDITION(S)
n
Operating the VCC supply voltage at the low end of the chip's specification (under 3.3V) may cause a
missmatch in the rising to falling rate.
Cypress Semiconductor Corporation
November 7, 2008
®
CY8CTMG200, CY8CTST200
®
CY8CTMG200 and CY8CTST200. Details include errata
Ω
to P1[3], P1[6], and P1[7] pins to restrict current to within latch-up limits.
