Silicon Errata for the CY8C22x13 PSoC
This document describes the errata for the PSoC
conditions, scope of impact, available workarounds, and silicon revision applicability. Compare this document to the
device's data sheet for a complete functional description.
Contact your local Cypress Sales Representative if you have questions.
Part Numbers Affected
Part Number
CY8C22x13
CY8C22x13 Qualification Status
Product Status: Production
CY8C22x13 Errata Summary
The following table defines the errata applicability to available CY8C22x13 family devices. An "X" indicates that the
errata pertains to the selected device.
Note Errata items, in the table below, are hyperlinked. Click on any item entry to jump to its description.
Items
[1]. Internal Main Oscillator
(IMO) Tolerance Deviation at
Temperature Extremes
1. Internal Main Oscillator (IMO) Tolerance Deviation at Temperature Extremes
PROBLEM DEFINITION
■
Asynchronous Digital Communications Interfaces may fail framing beyond 0 to 70°C. This problem does not
affect end-product usage between 0 and 70°C.
PARAMETERS AFFECTED
■
The IMO frequency tolerance. The worst case deviation when operated below 0°C and above +70°C and within
the upper and lower datasheet temperature range is ±5%.
Cypress Semiconductor Corporation
September 11, 2008
®
Mixed Signal Arrays
®
Mixed Signal Arrays CY8C22x13. Details include errata trigger
Ordering Information
CY8C22113-24PI
CY8C22113-24SI
CY8C22113-24SIT
CY8C22213-24PI
CY8C22213-24PVI
CY8C22213-24PVIT
CY8C22213-24SI
CY8C22213-24SIT
CY8C22213-24LFI
Part Number
Silicon Revision
CY8C22x13
•
198 Champion Court
Document No. 001-48788 Rev. **
A
Silicon fix is planned.
,
•
San Jose
CA 95134
CY8C22x13
•
408.943.2600
1
[+] Feedback
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cypress Semiconductor CY8C22x13
Summary of Contents for Cypress Semiconductor CY8C22x13
- Page 1 Product Status: Production CY8C22x13 Errata Summary The following table defines the errata applicability to available CY8C22x13 family devices. An "X" indicates that the errata pertains to the selected device. Note Errata items, in the table below, are hyperlinked. Click on any item entry to jump to its description.
