  • Page 1 CY8CKIT-031 ® ® PSoC CapSense Expansion Board Kit Guide Doc. # 001-66474 Rev. *A Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 Phone (USA): 800.858.1810 Phone (Intnl): 408.943.2600 http://www.cypress.com...
  • Page 2 Cypress against all charges. Any Source Code (software and/or firmware) is owned by Cypress Semiconductor Corporation (Cypress) and is protected by and subject to worldwide patent protection (United States and foreign), United States copyright laws and international treaty provisions.
  • Page 3: Table Of Contents

    Contents 1. Introduction Kit Contents .........................3 PSoC Creator ......................3 Getting Started......................4 Additional Learning Resources..................4 Document History ......................4 Documentation Conventions ..................4 2. Installation CD Installation ......................5 Hardware ........................6 Software........................6 3. Kit Operation 4. Example Projects Example Project 1: BMM_USB..................9 4.1.1 Project Description ...................9 4.1.2 Hardware Connections..................10 4.1.3 Verify Output ....................11...
  • Page 4 Contents CY8CKIT-031 PSoC CapSense Expansion Board Kit Guide, Doc. # 001-66474 Rev. *A...
  • Page 5: Introduction

    Introduction ® ® Thank you for your interest in the CY8CKIT-031 PSoC CapSense Expansion Board Kit. The PSoC CapSense Expansion Board Kit interfaces any of the CY3280 Universal CapSense Module boards with CY8CKIT-001 PSoC Development kit or CY8CKIT-030 PSoC 3 Development Kit. This kit enables you to develop CapSense solutions with the CY8C3280 Universal CapSense Module boards.
  • Page 6: Getting Started

    Introduction Getting Started To get started, go to Kit Operation chapter on page 7 for a description of the kit operation. This chapter explains how CapSense expansion board kit connects to develepement kit and CY8C3280 module boards. The Example Projects chapter on page 9 explains example projects provided with the kit.
  • Page 7: Installation

    Installation CD Installation To install the CY8CKIT-031 PSoC CapSense Expansion Board Kit software, insert the kit CD into the CD drive of your computer. The CD is designed to auto-run and PSoC CapSense Expansion Board Kit menu appears. Figure 2-1. Kit Menu Note If auto-run does not execute, double-click AutoRun on the root directory of the CD.
  • Page 8: Hardware

    Installation The set up installs following software: PSoC Creator ■ PSoC Programmer ■ Kit Documentation ■ Quick Start Guide ❐ Kit Guide ❐ Known Problems and Solutions ❐ Release Notes ❐ Firmware ■ Example Projects ❐ Hardware ■ Schematic ❐ Layout ❐...
  • Page 9: Kit Operation

    Kit Operation The following figure shows the CY8CKIT-031 PSoC CapSense Expansion Board Kit. Figure 3-1. CY8CKIT-031 PSoC CapSense Expansion Board Kit 2x20-Pin 2x22 Pin Connector for Connector for DVK Interface CapSense Interface 1x5 Pin Connector for I2C Interface The following figure shows CY3280 CapSense Matrix Button Module. Figure 3-2.
  • Page 10 Kit Operation Figure 3-4. PSoC CapSense Expansion Board Kit Interface with PSoC Development Kit and Universal CapSense Matrix Button Module Kit Figure 3-5. PSoC CapSense Expansion Board Kit Interface with PSoC 3 Development Kit and Universal CapSense Matrix Button Module Kit The 5-pin connector provides the I C interface.
  • Page 11: Example Projects

    Example Projects There are four example projects given with the kit. Example Project 1: BMM_USB Example Project 2: SLM_USB Example Project 3: BMM_I2C (Works only with MiniProg3) Example Project 4: SLM_I2C (Works only with MiniProg3) The projects are provided for the development kits: 1.
  • Page 12: Hardware Connections

    Example Projects The Sensitivity parameter in CapSense_CSD component configuration is set to 4 and project is tested to work without any overlay. When an overlay of some thickness is used, the sensitivity parameter should be changed in the project as shown in below Figure 4-1.
  • Page 13: Verify Output

    Example Projects 4.1.3 Verify Output Build and program the example project and reset the device. After device is reset, wait for Enumerate_LED to turn on. The LED indicates that 2 seconds wait time for the USB enumeration is over. Touch a button and see the corresponding row and column LED turns on. Open the calculator application in the PC, touch any button the corresponding key is pressed on calculator.
  • Page 14: Hardware Connections

    Example Projects 4.2.2 Hardware Connections If the development kit is PSoC Development Kit, then Connect the CapSense Linear Slider Module to connector J2 of PSoC CapSense Expansion ■ Board. Connect the J1 of PSoC CapSense Expansion Board Kit to the port A of the development kit. ■...
  • Page 15: Example Project 3: Bmm_I2C

    Example Projects Example Project 3: BMM_I2C Note: The project uses the Miniprog3. It does not work without MiniProg3 because the code waits forever in the main loop if I2C communication is not set up. User can buy MiniProg3 through this link www.cypress.com/go/CY8CKIT-002.
  • Page 16: Verify Output

    Example Projects 4.3.3 Verify Output Build and program the example project. If Miniprog3 is used for programming then disconnect the Miniprog3 from programming header and connect it to I2C connector J3 on PSoC CapSense Expansion Board Kit to use it for communication with GUI. Reset the device. Tuner GUI Usage: 1.
  • Page 17 Example Projects 3. Set the I2C communication parameters same as set in the EZI2C component. Note: The I2C Voltage should be other than External. The external supply pin on the MiniProg3 VTARG connects to NC on the CY8CKIT-031 board. Therefore the external supply option does not work with the CY8CKIT-030.
  • Page 18 Example Projects 5. To start the scanning and communication process, click Start button. 6. Open the Graphics tab; it shows different CapSense results RawCounts, Baseline, and Difference count (signal) for each sensor. 7. Check the graph to enable it. See graph for different variables. 8.
  • Page 19 Example Projects Figure 4-4. Graphs for Matrix Button Module Project CY8CKIT-031 PSoC CapSense Expansion Board Kit Guide, Doc. # 001-66474 Rev. *A...
  • Page 20: Example Project 4: Slm_I2C

    Example Projects Example Project 4: SLM_I2C Notes: The project uses the Miniprog3. It does not work without MiniProg3 because the code waits for- ■ ever in the main loop if I2C communication is not set up. User can buy MiniProg3 through this link www.cypress.com/go/CY8CKIT-002.
  • Page 21: Verify Output

    Example Projects 4.4.3 Verify Output Build and program the example project. If Miniprog3 is used for programming then disconnect the Miniprog3 from programming header and connect it to I2C connector (J3) to use it for communication with GUI. Reset the device. See Tuner GUI Usage in Verify Output on page 14 follow the steps.
  • Page 22 Example Projects Figure 4-6 shows the monitoring of RawCounts, Baseline, and Difference count (signal) for the Column 0 sensor. Figure 4-6. Graphs for CapSense Linear Slider Module Project Note: The CY8CKIT-001 PSoC Developement Kit gives lesser SNR performance. The kit is not designed to give optimal CapSense performance.
  • Page 23: Appendix

    Appendix Schematic GPIO2 GPIO1 GPIO1 GPIO2 GPIO4 GPIO3 GPIO3 GPIO4 GPIO5 GPIO6 GPIO6 GPIO5 GPIO7 GPIO8 GPIO8 GPIO7 GPIO10 GPIO9 GPIO9 GPIO10 GPIO12 GPIO11 NO LOAD GPIO11 GPIO12 GPIO13 GPIO14 GPIO14 GPIO15 GPIO16 GPIO13 GPIO16 GPIO15 GPIO17 GPIO18 GPIO18 GPIO19 GPIO20 NO LOAD GPIO21...
  • Page 24: Board Layout

    Board Layout A.2.1 PDC-09801 Top A.2.2 PDC-09801 Bottom CY8CKIT-031 PSoC CapSense Expansion Board Kit Guide, Doc. # 001-66474 Rev. *A...
  • Page 25: Bom

    Item Reference Value Description Manufacturer Mfr Part Number Cypress PDC-09801 Rev** CONN HEADER .100 DUAL R/A Sullins Electronics 40 Pin Header PBC20DBAN 40POS Corp. CONN FMALE 44POS DL .1" R/A Sullins Electronics 44 Pin Header PPPC222LJBN-RC GOLD Corp. CONN HEADER VERT 5POS .100 Molex/Waldom 5 Pin Header 22-28-4050...
  • Page 26 CY8CKIT-031 PSoC CapSense Expansion Board Kit Guide, Doc. # 001-66474 Rev. *A...
