1
ACCESSORIES
Attaching or detaching accessories
D Jack cover
CAUTION: DO NOT use the transceiver without the
connector cover or optional equipment attached.
The transceiver meets IP67 requirements for dust-
tight and waterproof protection only when the
connector cover or the HM-222HLWP,
HS-94LWP, or HS-95LWP is attached.
Attaching:
1. Place the jack cover over the speaker-microphone
jack. (q)
2. Insert and tighten the screws. (w)
w
q
w
FELLECS-TECH | inbox@fellecs-tech.com | www.fellecs-tech.com
Detaching:
1. Unscrew the screws using a Phillips screwdriver.
( z )
2. Detach the jack cover. ( x )
CAUTION: DO NOT detach the jack cover when
optional equipment is going to be used. Otherwise,
the terminals of the speaker microphone jack may be
shorted by a metal object or become rusty by water
intrusion. This could damage the transceiver.
2
z
x
z
