Cypress Semiconductor CY7C1381DV25 Specification Sheet

18-Mbit (512K x 36/1M x 18) Flow-Through SRAM
Features
• Supports 133 MHz bus operations
• 512K x 36/1M x 18 common IO
• 2.5V core power supply (V
• 2.5V IO supply (V )
DDQ
• Fast clock-to-output times, 6.5 ns (133 MHz version)
• Provides high-performance 2-1-1-1 access rate
• User selectable burst counter supporting Intel
interleaved or linear burst sequences
• Separate processor and controller address strobes
• Synchronous self timed write
• Asynchronous output enable
• CY7C1381DV25/CY7C1383DV25 available in
JEDEC-standard Pb-free 100-pin TQFP, Pb-free and non
Pb-free 165-ball FBGA package.
CY7C1381FV25/CY7C1383FV25 available in Pb-free and
non Pb-free 119-ball BGA package
• IEEE 1149.1 JTAG-Compatible Boundary Scan
• ZZ sleep mode option
Selection Guide
Maximum Access Time
Maximum Operating Current
Maximum CMOS Standby Current
Notes
1. For best practices or recommendations, please refer to the Cypress application note AN1064, SRAM System Design Guidelines on www.cypress.com.
2. CE CE are for TQFP and 165 FBGA package only. 119 BGA is offered only in 1 chip enable.
3, 2
Cypress Semiconductor Corporation
Document #: 38-05547 Rev. *E
)
DD
®
Pentium
• 198 Champion Court
CY7C1381DV25, CY7C1381FV25
CY7C1383DV25, CY7C1383FV25
Functional Description
The CY7C1381DV25/CY7C1383DV25/CY7C1381FV25/
CY7C1383FV25 is a 2.5V, 512K x 36 and 1M x 18
synchronous flow through SRAMs, designed to interface with
high-speed microprocessors with minimum glue logic.
Maximum access delay from clock rise is 6.5 ns (133 MHz
version). A 2-bit on-chip counter captures the first address in
a burst and increments the address automatically for the rest
of the burst access. All synchronous inputs are gated by
®
registers controlled by a positive edge triggered clock input
(CLK). The synchronous inputs include all addresses, all data
inputs, address pipelining chip enable (CE
chip enables (CE and CE
2
ADSP, and ADV), write enables ( BW
write (GW). Asynchronous inputs include the output enable
(OE) and the ZZ pin.
CY7C1381DV25/CY7C1383DV25/CY7C1381FV25/
The
CY7C1383FV25 allows interleaved or linear burst sequences,
selected by the MODE input pin. A HIGH selects an
interleaved burst sequence, while a LOW selects a linear burst
sequence. Burst accesses can be initiated with the processor
address strobe (ADSP) or the cache controller address strobe
(ADSC) inputs. Address advancement is controlled by the
address advancement (ADV) input.
Addresses and chip enables are registered at rising edge of
clock when either address strobe processor (ADSP) or
address strobe controller (ADSC) are active. Subsequent
burst addresses can be internally generated as controlled by
the advance pin (ADV).
The CY7C1381DV25/CY7C1383DV25/CY7C1381FV25/
CY7C1383FV25 operates from a +2.5V core power supply
while all outputs also operate with a +2.5 supply. All inputs and
outputs are JEDEC-standard and JESD8-5-compatible.
133 MHz
6.5
210
70
,
• San Jose CA 95134-1709
[1]
), depth expansion
1
[2] ), burst control inputs (ADSC,
3
, and BWE), and global
x
100 MHz Unit
8.5 ns
175 mA
70 mA
• 408-943-2600
Revised Feburary 14, 2007
