Cypress Semiconductor CY7C1361C Specification Sheet

9-Mbit (256K x 36/512K x 18) Flow-Through SRAM
Features
• Supports 100, 133-MHz bus operations
• Supports 100-MHz bus operations (Automotive)
• 256K × 36/512K × 18 common I/O
• 3.3V –5% and +10% core power supply (V
• 2.5V or 3.3V I/O power supply (V
• Fast clock-to-output times
— 6.5 ns (133-MHz version)
• Provide high-performance 2-1-1-1 access rate
• User-selectable burst counter supporting Intel
®
Pentium interleaved or linear burst sequences
• Separate processor and controller address strobes
• Synchronous self-timed write
• Asynchronous output enable
• Available in lead-free 100-Pin TQFP package, lead-free
and non lead-free 119-Ball BGA package and 165-Ball
FBGA package
• TQFP Available with 3-Chip Enable and 2-Chip Enable
• IEEE 1149.1 JTAG-Compatible Boundary Scan
•"ZZ" Sleep Mode option
Selection Guide
Maximum Access Time
Maximum Operating Current
Maximum CMOS Standby Current
Notes:
1. For best-practices recommendations, please refer to the Cypress application note System Design Guidelines on www.cypress.com.
2. CE is for A version of TQFP (3 Chip Enable Option) and 165 FBGA package only. 119 BGA is offered only in 2 Chip Enable.
3
Cypress Semiconductor Corporation
Document #: 38-05541 Rev. *F
Functional Description
The CY7C1361C/CY7C1363C is a 3.3V, 256K x 36/512K x 18
Synchronous Flow-through SRAMs, respectively designed to
interface with high-speed microprocessors with minimum glue
logic. Maximum access delay from clock rise is 6.5 ns
(133-MHz version). A 2-bit on-chip counter captures the first
)
DD
address in a burst and increments the address automatically
)
DDQ for the rest of the burst access. All synchronous inputs are
gated by registers controlled by a positive-edge-triggered
Clock Input (CLK). The synchronous inputs include all
addresses, all data inputs, address-pipelining Chip Enable
(CE
®
Control inputs (ADSC, ADSP, and ADV), Write Enables (BW
and BWE), and Global Write (GW). Asynchronous inputs
include the Output Enable (OE) and the ZZ pin.
The CY7C1361C/CY7C1363C allows either interleaved or
linear burst sequences, selected by the MODE input pin. A
HIGH selects an interleaved burst sequence, while a LOW
selects a linear burst sequence. Burst accesses can be
initiated with the Processor Address Strobe (ADSP) or the
cache Controller Address Strobe (ADSC) inputs. Address
advancement is controlled by the Address Advancement
(ADV) input.
Addresses and chip enables are registered at rising edge of
clock when either Address Strobe Processor (ADSP) or
Address Strobe Controller (ADSC) are active. Subsequent
burst addresses can be internally generated as controlled by
the Advance pin (ADV).
The CY7C1361C/CY7C1363C operates from a +3.3V core
power supply while all outputs may operate with either a +2.5
or +3.3V supply. All inputs and outputs are JEDEC-standard
JESD8-5-compatible.
133 MHz
6.5
250
Comm/Ind'l 40
Automotive
• 198 Champion Court
[1]
), depth-expansion Chip Enables (CE
1
100 MHz
8.5
180
40
60
,
• San Jose CA 95134-1709
Revised September 14, 2006
CY7C1361C
CY7C1363C
[2]
and CE ), Burst
2 3
,
x
Unit
ns
mA
mA
mA
• 408-943-2600
