Chapter 2 Install Your Product
2.1 Connect Input Signal
The camera or device with HDMI compliance can be input signal to TAO 1mini by HDMI interface.
You can also connect camera with USB interface to USB-C or USB-A interface of TAO 1mini.
Users can check the resolution of the input signal on the 2.1 inch touch screen when there is active
signal plug in.
2.2 Connect Power Supply
RGBlink TAO 1mini is packaged with a USB-C power link cable and a standard power adapter.
When connect the power supply, please check the power supply standard used in your country/area.
Besides, you can also use PoE module for power supply.
2.3 Connect HDMI Output
You can use an HDMI cable to connect TAO 1mini to a monitor with an HDMI input interface, so that
you can monitor the input, output and audio display in real time.
The HDMI output resolution of TAO 1mini is up to 4K@60.
2.4 Connect Network
Connect one end of the network cable to LAN port of TAO 1mini and the other end to the switch.
You can also connect directly to the network port of your computer.
