Chapter 6 Appendix

6.1 Specification

Interface Input
Output
Audio
Communication
Power
Performance HDMI 2.0 input
UVC/USB-C
input
Audio Input
LAN
TAO 1mini
HDMI 2.0 1×HDMI-A
UVC 1×USB-C
HDMI 2.0 1×HDMI-A
Input 1×3.5mm Audio Jack
LAN(PoE) 1×RJ45
USB 3.0 1×USB-A
USB-C 1×PD USB-C
LAN(PoE) 1×RJ45
Input resolution
720p@50/60 | 1080i@50/60 | 1080p@30/50/60
1280×720@50/60 | 1280×768@60 | 1280×1024@60 |
1366×768@60 | 1360×768@60 | 1600×900@60 |
1920×1080@50/60 | 3840×2160@60
Format YUV 4:2:2
Bit depth 8 bit/10 bit
Pixel format BT.601 | BT.709
Image delay 3 frames
1024×768@60 | 1280×720@50/60 | 1280×768@60 |
Input resolution 1280×1024@60 | 1360×768@60 |
1920×1080@24/25/30/50/60
Decoding
MJPEG/YUV | H.264 | H.265
performance
Audio delay setting 0~160ms
Analog audio input MIC/LINE
Maximum input level +6dBV
Coding performance Support MJPEG\YUV,H.264,H.265
