1.2.3 Connectors
2
1
7
No.
Connectors
1
USB-C
2
HDMI-OUT
3
USB-C
4
HDMI-IN
5
3.5mm Audio Socket For analog audio input and audio output monitoring.
6
USB 3.0
7
TAO 1mini
Description
Connect to the power supply, support PD protocol.
Connect to external monitor for real-time monitoring of inputs
and outputs.
For receiving video signal from your phone or others. Connect
to USB camera for UVC capture. Support 5V/1A reverse power
supply.
For receiving video signal.
Connect to hard disk for recording, and storage up to 2T.
LAN
Gigabit network port, support PoE.
User Manual
3
4
5
6
8
