HDMI 2.0
output
Power Mode
Input voltage
Maximum
power
Working
Temperature
Environment
Humidity
Physical Weight
Dimension

6.2 FAQ

1.There is an operation error/equipment abnormality, and it needs to be reset. How to reset?
A: Please try to unplug the power supply, power on and then turn on the device.
2.Does TAO 1mini support encoding and decoding at the same time?
A: Cannot. TAO 1mini supports two encoding function and decoding function, but it can only work in one
mode at the same time.
3. If TAO 1mini fails to record files and there is no recorded file in the U disk?
A: If you choose to stop recording, the interface will pop up a countdown prompt to remind you not to
unplug the U disk. Please keep U disk plugged in, otherwise the file will be damaged. (It is recommended to
use a U disk in FAT32 format, please avoid using a U disk in EXFAT format)
4.The HDMI signal cannot be recognized and there is no input source?
A: The input format does not support YUV444 format and HDCP format, please try to change the input
source. (the input source supports RGB/YUV422/YUV420 format)
TAO 1mini
Speed mode CBR,VBR,FIXQP,AVBR,QPMAP
RTMP coding Support streaming software
Maximum output
125Mbps
speed
Output resolution 720×480@30 | 1280×720@30 | 1920×1080@30/60 |
3840×2160@60
Audio Embedded audio output
PoE, PD
5~12V
10W
0℃~55℃
5%~85%
Product 180g
Packaged 780g
Product 91mm(diameter)×40.8mm(height)
Packaged 215mm x 145mm x 80mm
