Usb Recording - RGBlink TAO 1mini User Manual

Notice: When setting the NDI encoding resolution to 4K, the screen may turn to black, but TAO 1mini functions
normally.

3.2.3 USB Recording

Plug USB hard drive to TAO 1mini USB port and then TAO 1mini can work as a recorder.
The storage of USB disk is up to 2T.
Press and hold USB Recording icon to do the following settings.
TAO 1mini
Bitrate: Bit rate shows the real-time
encoding bit rate.Choose bitrate by swiping
the screen up and down. Click
confirm.
Encoding Format: FULL NDI, NDI|HX,
NDI|HX2, NDI|HX3 available, NDI|HX by
default. Click
Compression Format: H.264 and H.265
compression format for user to select.
Click to confirm.
Channel Name: Cannot be edited. HX
indicates format of NDI encoding, 100
indicates the last segment of IP address.
Users can revise channel name via
software.
User Manual
to confirm.
to
20
