B35 PEDAL HOUSING ( L )
B36 SCREW
B37 PEDAL REINFORCEMENT STRIP
B38 SCREW
C1 SIDE CONNECTING TUBE ( L )
C2 SIDE CONNECTING TUBE ( R )
C3 END CAP
C4 ADJUSTED NUT
C5 ADJUSTED END Φ50
D CONSOLE SUPPORTING TUBE
D1 SENSOR WIRE 350mm
D2 SENSOR WIRE 200mm
R1 SIDE TUBE COVER SET (R1)
R2 SIDE TUBE COVER SET (R2)
R3 SIDE TUBE COVER SET (R3)
R4 SIDE TUBE COVER SET (R4)
M1 BUSH
M2 CLIP R32
M3 MOTOR
2 J7 SCREW M12x73
4 J8 WASHER M12x20
4 J9 NUT M12
8 J10 SCREW M12x109
1 J11 HANDLE BAR SCREW
1 J12 HANDLE BAR SCREW
2 J13 SCREW M8x16
2 J14 WATER BOTTLE HOLDER SCREW
2 L1 SIDE TUBE COVER SET (L1)
1 L2 SIDE TUBE COVER SET (L2)
1 L3 SIDE TUBE COVER SET (L3)
1 L4 SIDE TUBE COVER SET (L4)
1 M4 SCREW
1 N1 BUSH Φ12.05*17*21.2mm
1 N2 CLIP (R40)
1 N3 BEARING 2203(MRB)
6 N4 SPACER RING (L)
8 N5 SPACER RING (R)
2 N6 SCREW
6
18
18
4
6
6
4
2
1
1
1
1
2
4
2
2
4
4
8
